Manufacturing Technology Study on Non-Backlash Double-Roller Enveloping Hourglass Worm

Abstract:

The processing of worm gear components is quite simple, and manufacturing method is relatively complete, theres no need to make special equipment. But to new energy equipment, research new-type of manufacturing technology is required. On the basis of meshing theory and drawing on manufacture of the planar enveloping as well as the tapper enveloping hourglass worm, a research of manufacture technique about the non-backlash double-roller enveloping hourglass worm drive has conducted on the Y3180E gear-hobbing machines and four-axis four-linkage NC machines. The key pieces have been processed out, and a calibration has been conducted on the single-head worm. All of these work will provid a theoretical foundation and practical experience for the actual manufacture.

• Periodical: Applied Mechanics and Materials (Volume 415)
• Pages: 524-528
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.415.524
• Online since: September 2013
• Authors: Jin Ge Wang, Rong He, Xing Qiao Deng, Le Xing Ren
• Keywords: Manufacturing Technology, New Energy Equipment, Non-Backlash, Y3180E
