The Food Warehouse Temperature Measurement System Design Based on Microcontroller

Abstract:

The thesis takes the microcontroller STC89C52 as the core control element. It selects the platinum thermal resistance PT100 sensor as a temperature detection element, and we use it to collect the temperature of the food warehouse act in concert with the Amplifier circuit and the ADC0809 analog-to-digital converter chip in real time. The collected temperature is displayed on the LCD1602 display module. According to the result of the comparison of the collected temperature values and setting values, this system gives off the corresponding alarm signal , and then starts the heating device or cooling device to achieve the purpose of controlling the temperature inside the warehouse, in this way, we can ensure the temperature of the warehouse in an appropriate range.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 1043-1048
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.1043
• Online since: September 2013
• Authors: Qi Bing Xia
• Keywords: Sensor, Single-Chip Microcomputer (SCM), Temperature Measurement, Warehouse Temperature

References

[1] Na Zhao, Gang Zhao, Zhenzhu Yu, et al. Temperature Measure System base on Single Chip 51 [J]. Microcomputer Information, 2007: 146.

[2] Jian Wu, Wen Hou, Bin Zheng. STC89C52 Single-chip based Temperature Control System [J]. Computer knowledge and technology, 2011: 902.

[3] Fengjuan Song, Chunsheng Wang, Xiuying Wang, et al. Application of Model 8051 SC Computer to Temperature Measurement Control System [J]. Journal of Tangshan College, (2007).

[4] Yong Yu, Jia Dai, Jiangzhu Chang. Examples for the Design of SCM 51 C Language Common Modules and Integrated Systems [M]. Beijing: Electronic Industry Press, (2007).
