The Simplest Mathematical Model and Simultaneous-Control Structure for Hobbing Helical Non-Circular Gear

Abstract:

To solve helical non-circular gears manufacturing problem, the simplest mathematical model for hobbing helical non-circular gear and simultaneous-control structure which the machine tool should have were researchedbeen researched. By comprehensive using of helical teeth meshing principles and helical tooling rack generation method, the simplest mathematical model for hobbing helical non-circular gear was deduced. The structure was a 4-axes simultaneous-control structure. Then, by applying the electronic-gear circuit module and electronic differential combination circuit module developed by the authors, simultaneous-control structure of CNC system which hobbing helical non-circular gear required was designed. Based on this, hobbing helical non-circular gears can be achieved, and helical non-circular gears manufacturing problem can be solved.

• Periodical: Applied Mechanics and Materials (Volume 42)
• Pages: 284-288
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.42.284
• Online since: November 2010
• Authors: Fang Yong Tian, Chi Bing Hu, Yan Cang Jiang
• Keywords: Helical Non-Circular Gear, Hobbing, Noncircular Gear, Simultaneous-Control Structure

References

[1] D.H. Hou, Z.M. Liu and X.T. Wu: Journal of Mechanical Engineering, Vol. 39 (2003) No. 8, pp.49-54 (In Chinese).

[2] F.S. Li: Non-circular Gears and Special Gears Design (China Machine Press, China 1983).

[3] D.H. Hou: Study on the Meshing Theory, Design and Manufacturing of the Special Variable- Transmission-Ratio Gear Drive (Ph.D., Xi'an Jiaotong University, China 2003).

[4] F.L. Litvin, I. Gonzalez-Perez, K. Yukishima and A. Fuentes, K. Hayasaka: Generation of Planar and Helical Elliptical Gears by Application of Rack-cutter, Hob, and Shaper, Comput. Methods. Appl. Mech. Eng., Vol. 196 (2007), p.4321–4336.

DOI: 10.1016/j.cma.2007.05.003

[5] M.F. Tsay and Z.H. Fong: Study on the Generalized Mathematical Model of Noncircular gears, Math. Comput. Modell., Vol. 41 (2005)p.555–569.

DOI: 10.1016/j.mcm.2003.08.010

[6] D. Mundo, G.A. Danieli, M. Maiorino, A. Pisano and A.F. Salatino: 11th World Congress in Mechanism and Machine Science (Tianjin, China, August 18-21, 2003). Vol. 2, pp.768-772.

[7] C.B. Hu and H.Y. Ding: China Mechanical Engineering, Vol. 15 (2004) No. 24, pp.2175-2178 (In Chinese).

[8] X.T. Wu: Non-circular Gears and Variable Ratio Transmission (China Machine Press, China 1997).

[9] W.M. Tan, C.B. Hu, W.J. Xian and Y. Qu: Journal of Mechanical Engineering, Vol. 37 (2001) No. 5, pp.26-29 (In Chinese).

[10] C.B. Hu, Y.P. Yao and Z.X. Wu: Journal of Manufacturing Technology and Machine Tool, (2003) No. 9, pp.41-42 (In Chinese).

[11] W.M. Tan, C.B. Hu and Z.H. Wei: China Mechanical Engineering, Vol. 9 (2003) No. 8, pp.24-27 (In Chinese).
