Establishing Mine Water Supply Network Physical Model Based on the Abnormal Similar Theory

Abstract:

It’s necessary to establish a perfect dust water supply system according to Coal mine safety regulations. In order to do researches on the reliability of mine dust water supply network, this paper deduces the similarity number of flow rate and pressure under the condition of abnormal similarity, and establish the physical model of mine water supply network according to the gravity similarity criterion at first in lin-nan mine as the background. Monitor the running status of the whole network, measure the flow rate and pressure of the monitoring stations, and then contrast the experiment result and EPANETH simulation result with the data of the original network. The results show that physical model meets gravity similarity under the condition of abnormal similarity, which provides the experimental basis for the follow-up research on mine water supply network.

• Periodical: Applied Mechanics and Materials (Volume 421)
• Pages: 850-854
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.421.850
• Online since: September 2013
• Authors: Zhong An Jiang, Lei Lei Shi, Pei Wang
• Keywords: Abnormal Similar, EPANETH, Gravity Similarity, Mine, Water Supply Network

References

[1] ZHANG Hong-wei, WANG Chen-wan, NIU Zhi-guang, et al. Constructing Method for the Physical Model of Municipal Water Distribution System. Journal of Tianjin University, Vol. 41(2008), p.860.

[2] YUE Lin, ZHANG Hongwei, WANG Zhen, et al. Research on Experimental Model for Water Distribution Network Based on Distorted Similarity Theory. CHINA WATER & WASTEWATER, Vol. 25(2009), p.45.

[3] YUE Lin. Research on Operating State of Water Distribution Network. Tianjin: Tianjin University, (2008).

[4] Yang Haibo，Hu Chengwei，Han Baoyun. Application of Similar Theory to the Computer Simulation of Tube Drawing. Journal University Science of Technology Beijing, Vol. 21(1999), p.285.

[5] Deuerlein, Jochen W. Decomposition model of a general water supply network graph [J]. Journal of Hydraulic Engineering, Vol. 134(2008), p.822.

DOI: 10.1061/(asce)0733-9429(2008)134:6(822)

[6] Qiang, Yue，Fan, Zhe-Chao; Zhao, Ming-Jie, et al. A new method to estimate the leakage amount at the water supply network nodes in the countryside regions/Applied Mechanics and Materials, 2012: 2386.

DOI: 10.4028/www.scientific.net/amm.170-173.2386

[7] Chang Kui, Gao Jin-Liang; Yuan Yi-Xing, et al. Simulation system of urban water supply network based on virtual reality. Journal of South China University of Technology (Natural Science), Vol. 36(2008), p.43.

[8] Hou Xiaodong. Study on Reliability and Optimization of Dustproof Water Supply Network System in Mine[Dissertation]. Beijing: University of Science and Technology Beijing, (2008).

[9] Chen Zhongqiu. Study and Application on Optimal Method of Water Supply pipeline Network of Mining. Beijing: University of Science and Technology Beijing, (2006).

[10] YU Jing-yang. The Dynamic Simulation of Hydraulics in Water Supply Network[Dissertation]. Anhui: Hefei University of Technology, (2006).

[11] Zhang Feng'e, Yin Zhining, Li Hong. Application of EPANET hydraulic model in water supplying network optimization. CHINA WATER & WASTEWATER, Vol. 33(2007), p.199.

[12] WANG Yu. The choice of water supply pipe network and tubes material. SHANXI ARCHITECTURE, Vol. 35(2009), p.179.
