Innovative Design of Applying TRIZ Technology to Safety Control of Low-Cost Electric Rolling Door

Abstract:

The electric rolling doors are extensively used in Taiwan; however, the accidents of personal injuries caused by electric rolling doors frequently occur. The doors have caused injuries, and even casualties in worst cases. Based on TRIZ contradiction matrix and inventive principles, this study used a laser module, a photoresistor receiver, and mirror reflected refraction to construct a low-cost safety control circuit device. This safety control circuit device can be used for electric rolling doors (3m high and 8m wide) that are commonly used for residential houses. When the electric rolling door is in operation, any objects of the height over 10cm entering or existing in the range of the electric rolling door can be detected by the control device. The actuation of the electric rolling door is then stopped, and an alarm gives out warning sound, so that possible injuries may be prevented. The material cost of this control device is below 2,000 NTD, and this design is cost-effective.

• Periodical: Applied Mechanics and Materials (Volume 421)
• Pages: 99-103
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.421.99
• Online since: September 2013
• Authors: Chin Jung Huang, Fa Ta Tsai
• Keywords: Electric Rolling Door, Laser Module, PhotoresistorReceiver, TRIZ

References

[1] Intellectual Property Office, Ministry of Economic Affairs, R.O.C. http: /twpat. tipo. gov. tw.

[2] Liao, W.C., Practical Application of TRIZ - Case Study of LCD screen turner", Master, s thesis, Master Program of Department of Industrial Engineering and Management, National Chiao Tung University (2006).

[3] Chen B.W., Improved Design of Bicycle Anti-lock Brakes by Utilizing TRIZ Theory", Master, s thesis, Graduate Institute of Manufactuimg Technology, National Taipei University of Technology (2011).
