Finite Element Analysis on Telescopic Suspension Arm of Dirt-Removing Crane Based on ANSYS

Abstract:

A finite-element mechanical model is established aiming at the features of telescopic suspension arm of dirt-removing crane in practice, such as that there exist many compound modes, the range of variation in lifting weight is big, etc. The strength, stiffness and stability of suspension arm is calculated and optimized based on ANSYS (software). The result of conventional design, which is checked and revised, tallies with the measured value relatively and may provide valuable reference for the design of suspension arm, which is to some extent significant to prolonging the fatigue life of cranes.

• Periodical: Applied Mechanics and Materials (Volumes 423-426)
• Pages: 1924-1928
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.423-426.1924
• Online since: September 2013
• Authors: Dong Dong Liang
• Keywords: Finite Element, Optimized Design, Suspension Arm

References

[1] Ren Yushan, Yu Xiangjun. Finite element calculation for adjustable box hoist boom and its optimal design. Journal of Changchun Institute of Technology. Forum Vol. 3(2007) 34-36.

[2] Tan Jianguo，Finite element analysis is carried out by adopting ANSYS 6，Peking Univetsity Press, Beijing, (2002).

[3] Wang Maocheng, Shao Min, The basic principle and numerical method of finite element method, Qinghua University Press, Beijing, (2001).

[4] Chen Ling, Song Pingnan, Finite element analysis for slewing jib crane based on ANSYS, Journal of Tianjin University of Technology. Forum Vol. 2(2005) 64-67.

[5] Zhou Zhenjie, Wang Xiping, The finite element analysis for the boom and jib of crawler cranes, Journal of Shangdong University, Forum Vol. 1(2005) 22-26.
