Vision Measurement for the Pose of Cannon Barrel

Abstract:

The pose measurement of cannon barrel (vertical angle and azimuth angle) is a difficulty and emphasis in the precision analysis of SPAAG fire control system. To solve this problem, this paper presents a contactless measuring method based on computer vision. Before measurement, fix a checked planar faceplate on the cannon barrel as a marker. Firstly, get the coordinate of X corner points using Harris Corner Detection Algorithm to calibrate the camera, and chalk up the cameras intrinsic parameters based on Extended Kalman Filter. Secondly, get the corner points from the image of test position, then calculate the extrinsic parameter matrix of the corresponding position combining with LSE algorithm. Finally, according to the motion model of cannon barrel and the position relative to the marker, derive the constraint equations between extrinsic parameter and vertical angle and azimuth angle, then figure out the two angles. Experiment validate the maneuverability and veracity of this method, and the results indicate that the measuring precision of this method is less than 1mil.

• Periodical: Applied Mechanics and Materials (Volumes 423-426)
• Pages: 2530-2535
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.423-426.2530
• Online since: September 2013
• Authors: Jian Dong Su, Xiu Sheng Duan, Jing Xiao
• Keywords: Cannon Barrel, Computer Vision, Fire Control System, Harris Algorithm, Kalman Filter (KF), Pose Measurement

References

[1] Guangjun Zhang. Vision measurement, Beijing: Science Press, 2007. In Chinese.

[2] Deepak Lawrence. K, Balakrishnan Ramamoorthy. Int J Adv Manuf Technol, 2011, 55: 611-62.

[3] Yongliang Xiao, Xianyu Su, Junpeng Xue, et al. Journal of Optoelectronics·Laser, 2011, 22(9): 1384-1389. In Chinese.

[4] Rujin Zhao, Qiheng Zhang, Haorui Zuo, et al. Journal of Optoelectronics·Laser, 2010, 21(6): 894-897. In Chinese.

[5] Xiaoling Zhang, Baofeng Zhang, Yuchi Lin, et al. Journal of Optoelectronics·Laser, 2010, 21(11): 1693-1697. In Chinese.

[6] Zimiao Zhang, Peng Wang, Changku Sun. Journal of Tianjin University, 2011, 44(5): 440~444. In Chinese.

[7] Fengmei Sun, Bo Wang. ACTA AUTOMATICA SINICA, 2011, 44(5): 440~444. In Chinese.

[8] Yang Guo, Xinhe Xu. CHINESE JOURNAL OF COMPUTERS, 2007, 30(7): 1195-1200. In Chinese.

[9] Zhengyou Zhang. A flexible new technique for camera calibration. IEEE Transaction on Pattern Analysis and Machine Intelligence, 2000, 22(11): 1330-1334.

DOI: 10.1109/34.888718

[10] Xiaoou Wang. The study on camera calibration method based on extended Kalman Filter. Harbin Institude of Technology, 2008. In Chinese.

[11] S. Lee, T. Kim, J. Choi. EEE Transactions on Consumer Electronics, 2009, 55(1): 27-33.

[12] Zhichao Chao, Sihua Fu, Qifeng Yu, et al. ACTA OPTICA SINICA, 2011, 31(3): 1~7. In Chinese.
