A Study on Fault Detection Algorithm for Motor Control Unit of Electric Vehicle

Abstract:

Algorithms for motor control unit in electric vehicles are being actively developed with consideration given to safety and reliability these days. Faults during driving are a critical problem that is directly linked to the safety of drivers, and studies on fault detection of control units in various situations are needed. This study investigated the faults of control units in a signal level interface with a dynamic model of drive motor and the real-time interconnection of motor control unit and HILS (hardware-in-the-loop simulation). It was found through real-time simulation that simulating the fault conditions with the sensors of motor control unit could reveal different characteristics of motor control unit. Furthermore, vehicle driving simulations with electric motor control were performed. The results of this study are expected to help the development of electric motor simulations and the evaluation of MCU and control algorithms.

• Periodical: Applied Mechanics and Materials (Volume 431)
• Pages: 226-230
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.431.226
• Online since: October 2013
• Authors: Dong Hyun Seo*, Wae Gyeong Shin, Jong Sang No
• Keywords: Dynamic Model, Electric Drive, Fault Insertion Model (FIU), Hardware Interrupt, Hardware-in-the-Loop Simulation (HILS), Motor Control Unit (MCU)

References

[1] M. Herniter, Z. Chambers, S. Prabhu, M. Stevens, M. Fowler, R. Fraser, Model-Based Design for Hybrid Electric Vehicle Development, EVS-22, (2006).

[2] Liu Qinghe Sun Zechang, Study on Electro-Hydraulic Parallel Brake System using HILS", Vehicle Power and Propulsion Conference, 2008. VPPC , 08. IEEE, 1 - 4, Sept. (2008).

DOI: 10.1109/vppc.2008.4677444

[3] Sung-Soo Kim and Wan Hee Jeong, Real-time multibody vehicle model with bush compliance effect using quasi-static analysis for HILS, Advances in Simulation of Multibody System Dynamics, Volume 22, Number 4.

DOI: 10.1007/s11044-009-9160-8

[4] M. Rezaei Darestani, M. Zareh, J. Roshanian, A. Nahvi, A Hardware-In-the Loop Experimental Setup for alaunch vehicle actuator, AIAA SPACE 2009 Conference & Exposition, 14 - 17 September (2009).

DOI: 10.2514/6.2009-6653

[5] Guoming Tang Tao Zhang Xin Liu Wei Liu Tao Mei, Vehicle hardware-in-the-loop simulation facility for driverless vehicle, Power Electronics and Intelligent Transportation System (PEITS), 22 -26, (2009).

DOI: 10.1109/peits.2009.5407031

[6] Daniel Lemp Susanne Köhl, Markus Plöger, ECU Network Testing by Hardware-in-the-Loop Simulation.

DOI: 10.1007/bf03224632

[7] Sehyun Kim, Kiyun Jeong, Rachung Kang, Inbeom Yang, Automatic Verification of Fault Detection Algorithm for MCU Using MCU-HIL Simulation Environment, 2013 KSAE Conference, 1 - 4 May (2013).

DOI: 10.1109/vppc.2012.6422553
