A New 3DGIS Development Technology Research Based on the Sketchup and SuperMap Platform

Abstract:

Analysis the pros and cons with the current three-dimensional GIS development techniques, we proposed a new three-dimensional GIS development technology based on Google Earth, Sketchup and SuperMap software, to better achieve the virtual digital of the three-dimensional model. The Google Earth software gets the two-dimensional area to be modeling image which imports into Google Sketchup software, establishment of two-dimensional vector graphics, and then build roads and construction of three-dimensional models. Then, SuperMap component realizes the integration of spatial data and attribute data integration management, the realization of digital based on data collection, classification, storage of property data and management. Based on this, we applied the development technology to the virtual campus three-dimensional navigation system. In this, some technology flow charts are given. Finally, compared with some other three-dimensional GIS development technologies, a discussion and conclusion presented. We call to apply three-dimensional GIS navigation.

• Periodical: Applied Mechanics and Materials (Volumes 433-435)
• Pages: 1379-1382
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.433-435.1379
• Online since: October 2013
• Authors: Bin Wu*, Shi Kai Duan, Ling Liu
• Keywords: Establish Model, Sketchup, SuperMap, Three-Dimensional GIS Technologies, Virtual Three-Dimensional Navigation

References

[1] ZhangYunyi. Empirical Research on the Relation of Ecological Environment and Sustainable Development in the Southwest of China, Environment protectionscience, 2010, 36(1): 28-31.

[2] X. H. Du, L. Wang, A. D. Sun, The development and application of GIS on power marketing and expansion, 2nd International Conference on Information Science and Engineering, pp.4143-4146, (2010).

DOI: 10.1109/icise.2010.5691593

[3] D. W. Seng, H.X. Wang, G.Y. Yue, 3D modeling and visualization of complex geological structures using OpenGL. Boundaries of Rock Mechnics, Proceedings of the international young scholars' symposium on rock mechanics, pp.935-938, May (2008).

DOI: 10.1201/9780203883204.ch174

[4] Rossmann J, Schluse M, Hoppen M. GIS-Based Virtual Testbeds and their Application to Forestry and City Simulation. 2010. 05.

DOI: 10.1115/winvr2010-3735

[5] Han, Yong; Qi, Yongyang; Chen, Yong , John Wiley and Sons Ltd. An integrated VR-GIS navigation platform for city/region simulation. United Kingdom, September-October (2010).

[6] D. Seng, Z. Song, 3D interactive visualization system for complex geologically related data. First international conference on intelligent networks and intelligent systems, pp.519-522, Nov. (2008).

DOI: 10.1109/icinis.2008.151

[7] Wang, kai, Based on the Google 3d campus navigation system research of the digital earth platform, October (2010).

[8] Chen DingGang, 3DModeling of Buildings Based on Google Earth, 2007. 5.

[9] Sui Haigang，Nong Yun，Nie Qianzhen, Chen Jiali . 3D aids to navigation setting based on GIS and virtual simulation, Wuhan University, Luojia Hill, Wuhan, China, August (2010).
