The Communication Protocol Design and Realization in the Testing System of Communication Devices

Abstract:

In order to realize the performance testing and fault diagnosis of communication devices in the Command and Control System, a testing system is proposed. In this paper, a novel communication protocol is developed to realize the communication between the host computer and lower computer of the testing system. As to the different functions of the testing system, the format and sense of the communication messages were introduced in detail. 15 kinds of messages were designed to complete the functions of the open and close of communication serial, data detection ports, the receive and transmission of detection data, the control of the I/O and so on. The communication protocol makes it possible to form the test path and achieve the test of different devices.

• Periodical: Applied Mechanics and Materials (Volumes 433-435)
• Pages: 1807-1812
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.433-435.1807
• Online since: October 2013
• Authors: Wen Bin Cao, Gang Niu, Guo Shun Chen, Gui Xiong Li, Qian Kun Yang
• Keywords: Communication Devices, Communication Protocol, Serial Communication, Testing System

References

[1] Guangzhou Zhiyuan Company. M22A-F/N/U20 MiniARM. (2008).

[2] Chengjun Wang. Analysis and Design of Self-difining Serial Port Communication Protocol. [J]. Computer Engineering. 2004, 30(24): 192-194.

[3] Guang Yang, Zhixiong Lei. Study on Remote Mmaintenance and Control System of the Equipment Seial Port Communication Protocol(SPCP)[J]. Electronical Technology. 2009, 46(1): 64-66.

[4] Jinbo Huang, Xiaoming Du, Jianfeng Lv. Research and Application of XML Database in the IETM. 2006(23): 79-82.

[5] Benkai Jia, Hui Zhuang, Guoping Wang, Suiping Guo, Zhilu Chen. Communication Protocol Design and Relization for the Very Small Aperture Terminal Satellite Station Remote Monitoring System[J]. Computer Measurement & Control. 2012, 20(8): 2240-2243.

[6] Xun Yu. The Research and Implement of the Ethernet MAC Protocol Based on IEEE 802. 3[D]. Tongji University. (2007).

[7] Chunsheng Xie, Tanlu Song, Cheng Shi. The Formulate Method of the Serial Communication Protocol[J]. Science and Technology Information. 2009(33): 64-66.
