Research on the Kinematics Simulation of Out-Moving Jaw Crusher Based on Nastran

Abstract:

In this paper, out-moving jaw crusher machine is regarded as the research object and we established the simulation model of virtual prototype based on Nastran. Through the simulation analysis of the movement process, trajectories of moving jaw side plate and a movable jaw toggle plate and related parameters were obtained and compared and verify the simulation model and theory model. The results show that: the simulation model reflects the motion characteristics of the theoretical model well. So it provides theoretical reference for improvement of dynamic performance analysis and structure design of jaw crusher and has important application value in engineering.

• Periodical: Applied Mechanics and Materials (Volumes 433-435)
• Pages: 63-66
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.433-435.63
• Online since: October 2013
• Authors: Jiang Yong
• Keywords: Kinematics Simulation, NASTRAN, Out-Moving Jaw Crusher
