Discrete Element Numerical Analysis and Experimental Study of Forces in Grinding of Granite

Abstract:

Grinding test was carried out to study the grinding of granite with single diamond grain. Forces were measured to investigate the mean normal and tangential forces acted on the diamond grain. The relationship between the forces and either spindle speed or the maximum thickness of the undeformed chip produced by a diamond grain was discussed. The digital models of granite were constructed by discrete element method. Based on the model, two-dimensional and 3-D analysis was carried out to simulate the grinding process with the single diamond grain. The simulation results were compared with experimental data, and some useful conclusions were obtained: the 3-D results agree well with the experiment data at the sameand largeas well as the sameand large; the 3-D and 2-D results are comparable to the experiment data at other machining parameters..

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 241-244
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.241
• Online since: October 2013
• Authors: Yong Ye*, Liang Kang
• Keywords: Discrete Element Method (DEM), Granite, Grinding Force, Grinding with Single Grain

References

[1] Li Yuan, Huang H, Zhu H M. Characteristics of the cutting forces when sawing granite[J]. Diamond and Abrasives Engineering, 2002, (2): 48-51. (in Chinese).

[2] Li Yuan, Yu Y Q, Xu X P. Measurement and analysis of cutting forces in circular sawing of granite[J]. Key Engineering Materials, 2001, 202-203: 293-298.

DOI: 10.4028/www.scientific.net/kem.202-203.293

[3] Cundall P. A. A computer model for simulation progressive large scale movements of blocky rock mechanics[A]. proceedings of Symposium of the International Society of Rock Mechanics[C], 1971，(1): 8–12.

[4] Wang Y J，Xing J B. Discrete Element Method and Its Application in Rock Mechanics. [M]. Shen Yang: Northeast institute of technology press, 1991. (in Chinese).

[5] Tan Y Q, Yang D M, Li C, Sheng Y. Discrete Element Method Simulation of Cracks in Monocrystalline Machining Process [J]. China Mechanical Engineering, 2008, 19(21): 2545-2548.

[6] Ye Y, Xu X P. Discrete Element Analysis and Experimental Validation of Forces in Grinding of Grainte with Single Diamond Grain. Tribology, 2009, 29(3): 215-219.
