The Design and Research of GMM Current Sensor

Abstract:

Due to the shortcomings of the traditional inductive current sensor and optical current sensor, a new type of current sensor with the application of Giant Magnetostrictive Material (GMM) is designed in this paper. This device has the advantages of none transient magnetic saturation, high precision, high response speed, and immune to environment temperature change. The structure design and operating principle of the GMM current sensor are introduced. Analyze the bias magnetic field, prestress force and material characteristics, and select the standard size of the GMM stick. Finally study the magnetic field interference on the application of electric transmission line one-phase measurement.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 710-715
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.710
• Online since: October 2013
• Authors: Yan Shen*, Heng Rong, Guo Qing Zhang, Wen Bin Yu, Zhi Zhong Guo, Yun He Lu
• Keywords: Bias Magnetic Field, GMM Current Sensor, Magnetic Field Interference, Pre-Stress

References

[1] Wang Jiaying, Guo Zhizhong, Zhang Guoqing, Shen Yan, Yu Wenbin. Experimental Investigation on Optical Current Transducer's Long-Term Operation Stability. Power System Technology. 36 (2012) 37~41.

[2] Li kuoshe, Xu Jing, Yang Hongchuan, Yuan Yongqiang, Xu Jianlin, Yu Dunbo, Zhang Shengen. Development of Rare Earth Giant Magnetostrictive Materials. China Rare Earth. 25 (2004) 51~56.

[3] Zhang Hongju. Study of the Rare Earth Giant Magnetostrictive Current Transformer. GUCAS Master Degree Thesis. (2008).

[4] Wang Xiaojing. Optical Current Transducer Research Direction and Actuality. Eletric Power Science and Engineering. 24 (2008) 34~36.

[5] Zhong Xiaojiang. Study of the FBG Current Sensor Based on Magnetostrictive Effect. North China Electric Power University Master Degree Thesis. (2007).

[6] Wang Bowen, Yan Rongge. Rare-earth Giant Magnetostrictive Materials, Application and Devices. Journal of Hebei University of Technology. 33 (2004) 16~22.

[7] Klaus Lenz. Present state of the art in new actuator technologies, Proc. Inter. Symp. On giant magnetostrictive materials and their applications. (1992) 69~72.

[8] Li Mingjin. Development of Study on Magnetostrictive Material and Its Preparation Methods. Development & Innovation of Machinery & Electrical Products. 18 (2005) 35~37.

[9] Guo Xiping, Gao Yaodong, Wang Jianxin. Establishment of Magnetostriction Properties Equation about Terfenol-D material. Science & Technology of Baotou Steel(Group) Corporation. 32 (2006) 27~41.
