Research and Simulation on Foot Trajectory of Zero-Slippage and Non-Laterodeviation

Abstract:

In order to test the result of straight-line walking driven by simple cycloid foot trajectory, a kind of quadruped robot is proposed and Adams software is used to simulate the gait. According to the results, the shortage of simple cycloid foot trajectory is analyzed, that the unequal velocity of supporting feet was the key cause of feet-slippage and laterodeviation in the process of simulation. Thereby, the supporting phase of cycloid gait is smoothed, so that the phenomenon of differential in supporting legs is eliminated and the foot velocity is guaranteed to be continuous. After simulation again, the results show that feet-slippage and laterodeviation are solved.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 798-802
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.798
• Online since: October 2013
• Authors: Lei Xi, Jian Zhong Shang*, Zi Rong Luo
• Keywords: Adam, Cycloid Gait, Foot Trajectory, Quadruped Robot

References

[1] Ding Liangxu, Wang Yunxiao, Feng Huashan, Brief Analysis of a BigDog Quadruped Robot, J. China Engineering, 23(2011) 505-514.

[2] BigDog, the Rough-Terrain Quadruped Robot, C. 17th IFAC World Congress (IFAC'08) Seoul, Korea, July 6-11, (2008).

[3] D.C. Kar, Design of Statically Stable Walking Robot: AA Review, J. Robotic Systems, 20(2003) 671-686.

DOI: 10.1002/rob.10118

[4] McGhee R B, Frank A A. On the Stability Properties of Quadruped Creeping Gaits, J. Math. Biosci, 3(1968) 331-351.

DOI: 10.1016/0025-5564(68)90090-4

[5] Zhang Wenyu, The study of omni-directional static walking and stability analysis of a quadruped robot on a slope, D. China Ocean University, (2009).

[6] Zhang Jinrong, Zhao Xi, The configuration design and kinematics analysis of quadruped robot, J. Modern Manufactory, 8(2009) 146-149.

[7] Zhang Jun, Li Shengjin, Lu Gang, Yan Weilian, Gain planning and kinematics analysis on the hydraulic pressure actuated quadruped robot, J. Mechanical Design, 26(2009) 28-31.

[8] Lei Jingtao, Gao Feng, Cui Ying, Foot Trajectory Planning and Simulation for a Hexapod Robot, J. Mechanical Design and Research, 22(2006) 42-46.

[9] Alexander C. Shkolnik. Sample-Based Motion Planning in High-Dimensional and Differentially-Constrained Systems, D. Massachusetts Institute of Technology, (2010).

[10] Wen Huaixing, Liu Jianhua, Lu Jianxiao, Virtual design and structural optimization of a kind of robot gripper based on ADAMS, J. Machinery Design and Manufacture. 3(2010) 75-78.

[11] Wang Lipeng, Wang Junzheng, Wang Shoukun, He Yudong, Strategy of Foot Trajectory Generation for Hydraulic Quadruped Robots Gait Planning, J. Journal of Mechanical Engineering 1(2013) 39-44.

DOI: 10.3901/jme.2013.01.039
