Research of 220KV Smart Substation Simulation Training System Modeling Method

Abstract:

In this paper, the simulation support software and the simulation application software have been used to reappear the functions of 220kv Yanling substation by computer. And the simulation training system provides some functions in control such as dealing with abnormal or accident, operation record. Besides the function of the conventional simulation training system, the function of intelligent equipment operation, and the display and data acquisation are simulated, and the data transmission of MMS nets, GOOSE nets and SV nets are simulated. The relay protection with point-to-point analogy acquisition and point-to-point trip, and the advanced application of a key sequence control, abnormal and accident treatment of the smart substation are also simulated. Now the system has been completed and put into use.

• Periodical: Applied Mechanics and Materials (Volume 437)
• Pages: 880-887
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.437.880
• Online since: October 2013
• Authors: Gui Jie Ni*, Yang Wu, Yong Jie Zhai, Guo Hong Liu
• Keywords: Model, Smart, Substation
