Design and Implementation of RF Front-End for GPS Receiver Utilizing Discrete Components

Abstract:

A GPS radio frequency (RF) front-end based on discrete components is designed and implemented in this paper. Research on the structures of RF front-ends for GPS receivers, and an intermediate frequency (IF) digitalization front-end is expounded in details. Analyze the design considerations of filter bandwidth, sampling frequency, quantization bits, and automatic gain control, which would effect on the whole performance of RF front-end. Then, appropriate discrete components are selected, and a low IF RF front-end hardware platform with orthogonal structure is implemented. Test results indicate that the hardware platform combined with base-band module could effectively complete signals acquisition.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 1330-1334
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.1330
• Online since: December 2010
• Authors: Ji Cheng Ding, Lin Zhao, Shuai He Gao, Li Xiong Xia, Jun Ling Zhang
• Keywords: Automatic Gain Control (AGC), Bandpass Sampling, Bandwidth (BW), Quantization Bit, RF Front-End

References

[1] Andrew G. Dempster. Satellite Navigation: New Signals, New Challenge, IEEE International Symposium on Circuits and Systems. (2007).

DOI: 10.1109/iscas.2007.377927

[2] Jong-Moon Kim, Ho-Jun Song, Young-Back Kim. Design and implementation of L1-band C/A-code GPS RF front-end chip, The 6th International Conference on VLSI and CAD, pp.372-375. (1999).

DOI: 10.1109/icvc.1999.820934

[3] Piazza, Qiuting Huang. A 1. 57-GHz RF front-end for triple conversion GPS receiver, Solid-State Circuits, 1998. vol. 33, no. 2, pp.202-209. (1998).

DOI: 10.1109/4.658621

[4] Akos, Tsui. Design and implementation of a direct digitization GPS receiver front end, Proceedings of the 1996 40th Annual IEEE MTT-S International Microwave Symposium, pp.44-51. (1996).

DOI: 10.1109/mwsym.1996.512184

[5] Pratap Misra, Per Enge. Global Positioning System: Signals, Measurements and Performance, Ganga-Jamuna Press, pp.340-337. (2008).

[6] James T. Curran, Daniele Borio, Colin C. Murphy, et al. Reducing Front-End Bandwidth may Improve Digital GNSS Receiver Performance, http: /plan. geomatics. ucalgary. (2010).

DOI: 10.1109/tsp.2009.2037860

[7] RG Vaughan, NL Scott, DR White. The Theory of Bandpass Sampling, IEEE Transaction on signal processing, vol. 39, no. 9, pp.1973-1984. (1999).

[8] Daniele B. A Statistical Theory for GNSS Signal Acquisition, Ph. D Thesis, Dottorato in Elettronica edelle ComunicazioniXX ciclo. (2008).

[9] Cillian O'Driscoll B.E. Performance Analysis of the Parallel Acquisition of Weak GPS Signals, Ph. D thesis, The National University of Ireland, January. (2007).
