Design, Preparation and Application of Dual-Color HgCdTe Infrared Sensor

Abstract:

In the paper, the principle, the preparation and the performance of the dual-color infrared HgCdTe detector is introduced. The detector is a combination of different wave band filter and different respond wave band element. The application of the dual-color infrared HgCdTe sensitive element for methane gas detection sensor is developed. A two-element HgCdTe methane detector which responds between 3.13~3.53μm and 3.91~4.09μm wave bands respectively was reported. The performance of each detection channel was presented. The experiment test and analyze are fulfilled. The experiment result indicates that under the refrigeration temperature the dual-color HgCdTe detector not only has a favorable response ability and repetition but also can realize the response and distinguish ability to methane gas through integrate narrow band filter on the front of the detector sensitive element.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 2055-2059
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.2055
• Online since: December 2010
• Authors: Qiu Lin Tan, Chen Yang Xue, Wen Dong Zhang, Ji Jun Xiong, Jun Liu
• Keywords: Dual-Color, Gas Detector, HgCdTe, Infrared

References

[1] Norton Paul R, SPIE, 1998, 3379, 102 ~114.

[2] Rogalski, Antoni, Progress in Quantum Electronics, 2003, 27, 59-210.

[3] Zanatta J. P, Noel F, et al., Journal of Electronic Materials, 2003, 32, 602-607.

[4] Rajavel R. D, Jamba D. M, Wa. O. K, et al., 1997, 175/176, 653~658.

[5] Antoni Rogalski, SPIE, 2000, 3948, 17~30.

[6] Jürgen Schilz, PerkinElmer Optoelectronics. (2000).

[7] Reine M. B, Norton P. W, Starr R, Journal of Electronic Materials, 1995, 24, 5, 669~678.

[8] Musca C. A, Siliquini J. F, et al., 1998, 184/185, 1284~1287.

[9] Ye Zhen-Hua, Wu Jun Hu, et al., Journal of Infrared and Millimeter Waves, 2004, 3, 193~196.

[10] Antoszewski J, Winchester K. J, 2005, 34, 716~721.

[11] Endres H. E, Jander H. D, Göttler W, Sensors and Actuators B: Chemical, 1995, 23, 163~172.

DOI: 10.1016/0925-4005(94)01272-j

[12] Tan Qiulin, Zhang Wendong, Xue Chenyang et al. Optics & Laser Technology, 2008, 40 : 703–710.
