Serial Communication and Temperature Monitoring of MSMA Actuator Based on DS18B20

Abstract:

The magnetically controlled shape memory alloy (MSMA) is a new type of intelligent materials, which has large strain and high efficiency of electromechanical energy conversion, however, temperature has great influence to it. The DS18B20 digital thermometer provides 9-bit to 12-bit Celsius temperature measurements, which has an operating temperature range of -55 Degrees Celsius to +125 Degrees Celsius and is accurate to ±0.5 Degrees Celsius, Therefore it’s used to monitor the temperature of MSMA actuator in this paper. Serial communication is very important in our daily life; the paper mainly introduces hardware and software design for it and serial communication between pc and c51 based on matlab, meanwhile, drawing temperature curve by existing functions of matlab.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 2973-2977
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.2973
• Online since: December 2010
• Authors: Hua Wei Ji, Yong Qing Wen
• Keywords: C51, DS18B20, MSMA Actuator, Serial Communication

References

[1] Wu Xinjie, Wang Fengxiang, Zhang Qingxin. MSMA actuators and its application prospect, Materials Review, 2003(9), PP. 16—18.

[2] Tapani Jokinen, Kari Ullakko, Ilkka Suorsa. Magnetic shape memory materials-new possibilities to create force and movement by magnetic fields [A]. Wang Feng-xiang, Tang Ren-yuan. Proceedings of the Fifth International Conference on Electrical Machines and Systems[C]. Shenyang: International Academic Publi- shers , 2001. 20 -23.

DOI: 10.1109/icems.2001.970600

[3] DSl8B20 Programmable Resolution 1-Wire Digital Thermometer, Dallas Semiconductor, 2003, pp.11-14.

[4] Math works Corp. Instrument Control Toolbox [Z], (2000).

[5] MATLAB Instrument Control Toolbox Specifications. The Math works, Inc, June, 18, 2002, Version 6. 5.
