Profile Error Synthetic Analysis of One-Side Milling of the Inner Engaged Globoidal Cam

Abstract:

After making a detailed analysis about the one-side machining theory, based on the homogeneous coordinate transformation and the conjugate meshing theory of spatial mechanisms, applying Newton’s iteration, this paper realizes the synthetic analysis of the one-side milling profile error about the inner engaged globoidal cam for the potential cutter error and installation inaccuracy. A computer simulation example is presented, and the results can effectively disclosure and predict the law of influence of the various errors on the cam profile normal error. Consequently, a scientific proof has been supplied to improve the precision and quality of the one-side machining of the inner engaged globoidal cam.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 758-766
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.758
• Online since: December 2010
• Authors: Lian Jin, Zheng Kuang, Zi Hua Hu, Liang Tang, Ju Long Yuan
• Keywords: Error Synthetic Analysis, Inner Engaged Globoidal Cam, Normal Error, One-Side Machining

References

[1] Lizhong Xu, Yulin Yang, Zhen Huang. General Review of the Study on the Toroidal Drive. Engineering Science Vol. 2(2000), pp.84-88, in Chinese.

[2] Kuehnle.M. R, Peeken H, Troeder C and Cerniak S. The Toroidal drive. Mechanical Engineering Vol. 2(1981), pp.32-39.

[3] The Toroidal Drive—a new concept in mechanical transmission. 26th Design Engineering Conference, Sep, (1979).

[4] Lizhong Xu. Toroidal Drive (China Machine Press, Beijing 2005), in Chinese.

[5] Guowu Wei. The Research on Toroidal Drive (Dissertation, Fuzhou University, 2004), in Chinese.

[6] Lizhong Xu. Study on the comprehensive design theory and manufacture technology of the toroidal drive (Dissertation, Yanshan University, 1999), in Chinese.

[7] Ligang Yao, Xiaojun Xu. Research on manufacturing the stator of toroidal drive by enveloping method. Mechanical transmission Vol. 3(1996), pp.24-26, in Chinese.

[8] Xingjian Nie, Dingfang Chen. Analysis and trail manufacture of toroidal reducer. Mechanical design Vol. 3(1988), pp.66-71, in Chinese.

[9] Zihua Hu, Ping Zhang, Rui Qi. A study on multi—axis NC machining processes for continuous indexing globoidal cams. China mechanical engineering Vol. 16(2005), pp.2184-2187. in Chinese.

[10] Ligang Yao. The Research on Toroidal Drive. Journal of Harbin Institute of Technology Vol. 3(1998), pp.75-77, in Chinese.

[11] Gaofeng Zhang, Shiping Yang, Chen Huazhang. Application of D-H method on the design of globoidal indexing cam mechanism. Machine transmission Vol. 4(2003), pp.46-18, in Chinese.

[12] Gaofeng Zhang, Zhaohui Deng, Yuanqiang Tan. The Design of Planet Globoidal Cam Reducer. Mechanism Journal of Hunan University(Natural Sciences) Vol. 6(2006), pp.55-58, in Chinese.

[13] Mingfu Yin, Zhenhong Zhao. Study on One-side machining principle and tool path control method of the globoidal cam. China mechanical engineering Vol. 2(2005), pp.127-130, in Chinese.
