Dimensional Synthesis of a 4-DOF Hybrid Driving Platform

Abstract:

A novel 4-DOF hybrid driving platform of flight simulator is presented. Its main load born by a PU limb which composed of pneumatic support unit, so the driving force, the safety and the simulation performance are all improved. The simulation performance is proposed to be taken as the evaluating index. Dimensional optimization of the driving platform is studied with the aid of the characteristics of Rayleigh quotient and vector. The influence law of scale parameters to simulation performance and constraints is discussed through monotonic analysis and it is adopted to seek the optimal solution of the simulation performance. The effectiveness of the method is proved by the example.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 543-547
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.543
• Online since: December 2013
• Authors: Zhen Yu Hong, Zhi Xu Zhang, Zhi Hua Xu
• Keywords: Dimensional Synthesis, Driving Platform, Rayleigh Quotient, Simulation Performance

References

[1] POULIOT N A, GOSSELIN C M, Motion simulation capabilities of three-degree-of-freedom flight simulators. Journal of Aircraft, 35(1): 9-17, (1998).

DOI: 10.2514/2.2283

[2] PIERROT F, NABAT V, COMPANY O, et al. Optimal design of a 4-DOF parallel manipulator: From academia to industry. IEEE Transactions on Robotics, 25(2): 213-224, (2009).

DOI: 10.1109/tro.2008.2011412

[3] MERLET J P, DANEY D. Dimensional synthesis of parallel robots with a guaranteed given accuracy over a specific workspace/ Proceedings of the 2005 IEEE International Conference on Robotics and Automation, April, 18-22, 2005, Barcelona, Spain. New York: IEEE, 2005: 942-947, (2005).

DOI: 10.1109/robot.2005.1570238

[4] Laribi, M.A. , ROMDHANE, L.: submitted to Mechanism and Machine Theory (2007).

[5] Meng Li. Design theory and methodology of the TriVariant－a 5-DOF reconfigurable PKM module. Tianjin University, 2005. In Chinese.

[6] LOU Y J, ZHANG D J, LI Z X. Optimal design of a parallel machine based on multiple criteria/Proceedings of the 2005 IEEE International Conference on Robotics and Automation, April 18-22, 2005, Barcelona, Spain. New York: IEEE, 2005: 3 219-3 224, (2005).

DOI: 10.1109/robot.2005.1570606

[7] Tian Huang, Xingyu Zhao. Stiffness estimation of a tripod-based parallel kinematic machine. IEEE Transactions of Robotics and Automation, 18(1): 50-58, (2002).

DOI: 10.1109/70.988974

[8] Limin Zhang, Jiangping Mei, Xueman, Zhao. Dynamic Dimensional Synthesis of Delta Robot . Chinese Journal of Mechanical Engineering, 46 (3): 1-7, 2010. In Chinese.

[9] HAO F, MERLET J P. Multi-criteria optimal design of parallel manipulators based on intervalanalysis. Mechanism and Machine Theory, 40(2): 157-171, (2005).

DOI: 10.1016/j.mechmachtheory.2004.07.002
