Aluminum-Clad Invar Super Heat-Resistant Aluminium Alloy Stranded Wire Sag Calculation

Abstract:

Comparison with conventional ACSR aluminum clad ultra-resistant aluminum alloy invar wire with low sag, load flow characteristics, linear expansion coefficient of the wire there is migration point, the migration point temperature coefficient of linear expansion around the wire is different, therefore can not be directly calculated using the equation of state migration point directly after the aluminum clad super-resistant aluminum alloy invar wire sag. This combined with engineering examples, the wire sag derived formulas, combined with the current reality of the design units, presents a practical algorithm for reference.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 58-61
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.58
• Online since: December 2013
• Authors: Guo Ju Han
• Keywords: Invar, Migration Point, Sag, Wire

References

[1] Wang Guozhong Huang Hao Shi, energy-efficient expansion stresses and wire sag calculation [J]. Wires and cables, 2009 (5): 11-12.

[2] Zhang Diansheng editor, high voltage transmission line electrical engineering Design Manual, (second edition) [M], Beijing, China Electric Power Press, (2003).

[3] Shaotian Xiao of overhead transmission line wire mechanical calculations, (second edition) [M], Beijing, China Electric Power Press, (2003).
