Vibration Characteristics Analysis for the Stator of Dynamic Friction Linear Piezoelectric Stack Motors

Abstract:

To improve the output performance of piezoelectric linear motors, researches was carried on the vibration characteristic for the stator of dynamic-friction type non-resonant linear piezoelectric motors. By analyzing the construction and working mechanism of the motor, longitudinal vibration model was established for the stator of motor. Then the vibration differential equation of the drive tip was deduced and longitudinal displacement functions were proposed. Further, the prototype was fabricated and investigated by experiments on the longitudinal displacement of drive tip under different excitation conditions. Experiment results proved the vibration characteristic theory of stator that the longitudinal amplitude of drive tip increases with excitation voltage. The maximum amplitude of drive tip is 0.85μm and the output force is 3 N on condition that the operation voltage is 90 V and the frequency is 1.6 kHz. The above studies can provide theoretical basis for performance optimization of motor and for structural optimization of stator.

• Periodical: Applied Mechanics and Materials (Volume 442)
• Pages: 392-396
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.442.392
• Online since: October 2013
• Authors: Xi Fu Chen, Yu Liang, Wei Qing Huang*, Hai Zhou
• Keywords: Linear Motors, Piezoelectric Stacks, Stator, Vibration

References

[1] PAN S, HUANG WQ, WANG Y, et al. . Optics and Precision Engi, Vol. 19, 2464-2471 ( 2011).

[2] Yunlai Shi, Chunsheng Zhao. Ultrasonics, Vol. 51, 397-404 ( 2011).

[3] Kim Jaehwan, Lee Jin-Ho. Smart Materials and Structures, Vol. 14, 934-940 ( 2005).

[4] Shi Yunlai, Li Yubao, Zhao Chunsheng. Proceedings of the CSEE, Vol. 30, 56-60(2008).

[5] Xu Xu, Liang Yanchun, Shi Xiaohu. Journal of Jili University: Science Edition, Vol. 40, 109 -113(2002).

[6] Zhao Hongwei．Basic theory and experimental study on inchworm-type piezoelectric actutor[D]. Jilin：Jilin University(2006).

[7] Wen Jianming．Study on planar inertia piezoelectric moving mechanism[D]．Jilin：Jilin University(2009).
