Finite Element Thermal Analysis of the Packing Container in Fire Environment

Abstract:

The packing container is used in storage and transport of the high explosive (HE) material. The study concerns the safety of the packing container in fire environment. The spruce wood filled in the packing container can effectively resist heat transfer and protect HE material. The thermal analysis of the packing container in the pool fire environment is presented with the finite element method. When considering the water evaporation and the wood pyrolysis, the enthalpy curve of wood is presented in this study. Heat can be transferred from the fire to the packing container via convection and radiation. Thus, two thermal boundary conditions are applied to the thermal model of the packing container. The simulations show the inner temperature distributions of the packing container are significantly affected by the wood-column thickness. For the same time, the simulations show there is a slight difference in the char layer thickness between two thickness wood columns. The computed results show there are large temperature gradients in the interface of char and wood. This demonstrates the spruce wood is the excellent thermal resistance material.

• Periodical: Applied Mechanics and Materials (Volumes 444-445)
• Pages: 1539-1544
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.444-445.1539
• Online since: October 2013
• Authors: Peng Huang, Zhi Ming Hao, Wei Fen Li, Shao Quan Hu
• Keywords: Enthalpy Curve, Finite Element Method (FEM), Packing Container, Thermal Analysis

References

[1] M.H. Li, G.L. Zhai, Y.Z. Song, et al., Design and performance analyses of thermal protection structure of accident-resistant packaging containe, Packaging Engineering, 21 (2000) 5-8. (in Chinese).

[2] M.H. Li, J.X. Ren, Q.S. Luo, et al., Numerical simulation of the thermal response of steel-wood composite structure on fire, Journal of Tsinghua University (Sci & Tech), 41 (2001) 68-71. (in Chinese).

[3] H. Takeda, J. R. Mehaffey. WALL2D: a model for predicting heat transfer through wood-stud walls exposed to fire, Fire and Materials, 22 (1998) 133-140.

DOI: 10.1002/(sici)1099-1018(1998070)22:4<133::aid-fam642>3.0.co;2-l

[4] G. Thomas, Modelling thermal performance of gypsum plasterboard-lined light timber frame walls using SAFIR and TASEF, Fire and Materials, 34 (2010) 385-406.

DOI: 10.1002/fam.1026

[5] S.T. Craft, B. Isgor, G. Hadjisophocleous, et al., Predicting the thermal response of gypsum board subjected to a constant heat flux, Fire and Materials, 32 (2008) 333-355.

DOI: 10.1002/fam.971

[6] L. Lu, O. B. Isgor, G. Hadjisophocleous, A computer model for light-frame wood floor assemblies under fire attack, 11th World Conference on Timber Engineering, City of Riva del Garda, Italy, (2010).

[7] R.W. Lewis, P. Nithiarasu, K.N. Seetharamu, Fundamentals of the finite element method for heat and fluid flow, John Wiley & Sons Ltd, Chichester, (2004).

DOI: 10.1002/0470014164
