Based on CFX Numerical Simulation of Francis Turbine Runner

Abstract:

This paper presents a vibration prediction method for Francis turbine: Provided with advanced CFX software, Numerical simulation of movable guide vane and Turbine runner’s internal flow state. From the source of hydraulic vibration, Focus on numerical analysis, numerical simulation for the cutting thickness of the runner blade. After analysis of the influence of the blade of hydraulic vibration. To explore new ways for the hydro turbine control hydraulic vibration.

• Periodical: Applied Mechanics and Materials (Volume 456)
• Pages: 207-210
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.456.207
• Online since: October 2013
• Authors: Fang He
• Keywords: CFX, Hydraulic Vibration, Numerical Simulation, Turbine Runner

References

[1] C.M. Liu: Analysis of the internal flow in Francis turbine runner CFD (MS., XiHua University, China 2006).

[2] Z.G. Fang, X.X. Guo, J. Yan: 2nd International Workshop on Intelligent Systems and Applications (Wuhan, China, May 22-23 2010), pp.1-3.

[3] G.S. Wang, G.L. Wang, L. Gu, et al: Chinese Hydraulics & Pneumatics, (2003) no. 5, pp.42-45. (In Chinese).

[4] C.B. Tong: Digital Manufacturing Industry, (2008) no. 6, pp.66-69. (In Chinese).
