A Study on the Method for Punching Small Holes with Cold Stamping Dies

Abstract:

this paper first determines the deformation modes of punching small-hole punches by analyzing the forms of the stress applied to die working parts. It analyzes the disadvantages of existing methods for preventing the buckling problem in punching small holes such as protective jackets and proposes a method for preventing the buckling of punches by reducing the punching force so as to make it possible to punch smaller holes.

• Periodical: Applied Mechanics and Materials (Volume 456)
• Pages: 358-362
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.456.358
• Online since: October 2013
• Authors: Jian Hua Ning, Zheng Ping Hai
• Keywords: Buckling, Process for Second Punching, Punching Small Holes
