Research on Passivity-Based ADRC of Direct-Drive Wind Power System Back to Back PWM Converter

Abstract:

In order to improve the performance of the converter for restrain the machine-side PWM rectifier load disturbance impact on the output DC voltage in direct-drive wind power system. A hybrid control strategy based on ADRC and the EL model was presented, using ESO to observe and compensate the load disturbances, achieving voltage outer control by ADRC method and comparing with PI control. However, as to grid-side PWM inverter, energy shaping method which based on PCHD model and the IDA-PBC control algorithm is adopted to design passivity-based controller, which is able to make the energy function have the minimum value when inverter is at the desired point, thus improving the stability and the load disturbance-rejection ability for the inverter. Simulation results show that the machine-side PWM rectifier can make the currents and voltages of AC side achieve synchronous, DC voltage can fast-track desired values; grid-side PWM inverter can achieve unity power factor and make the AC current sinusoidal.

• Periodical: Applied Mechanics and Materials (Volumes 457-458)
• Pages: 1363-1370
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.457-458.1363
• Online since: October 2013
• Authors: Xian Qin Ma, Jiu He Wang
• Keywords: ADRC, Direct-Drive Wind Power System, Passivity-Based Control, PCHD

References

[1] Wang jiuhe. Nonlinear Control for Voltage Source PWM Rectifier [M]. Beijing: Mechanical Industry Press, (2008).

[2] Zhang Xing, ZHANG Chongwei. PWM rectifier and its control [M] Beijing: Mechanical Industry Press, (2012).

[3] Yao Jun, LIAO Yong, Li Hui, etal. Unity power factor control of a direct-driven permanent magnet synchronous wind-power generator [J]. Electric Machines and Control, 2010, vol. 14, pp.13-20.

DOI: 10.4028/www.scientific.net/amr.347-353.2227

[4] LI Jianlin, GAO Zhigang, HU Shuju, etal．Application of parallel back-to-back PWM converter on the direct-drive wind power system[J]. Automation of Electric Power Systems, 2008, vol. 3 , pp.59-62.

DOI: 10.1109/drpt.2008.4523832

[5] Kuo Yuan Bo, Zhou Xin, Zhang Xiaohua. Three-phase PWM Voltage Rectifier control researcher based on ADRC [J]. Automation of Electric Power Systems, 2011, vol. 3, pp.87-93.

[6] Zhao jiumei, Ren Yifeng. Application of Active Disturbance Rejection Control in PWM Rectifier [J]. Electrical Technology, 2010, vol. 7, pp.53-55.

[7] Shui xingxin, Xie yunxiang, Yang jinming. Optimal Control of Single-Phase Full-Bridge Inverters by State Feedback Linearization [J]. Electric technical Society, 2009, vol. 24, pp.120-126.

[8] Wang jiuhe. Passivity-Based control theory and its application [M]. Beijing: Electronic Industry Press, (2010).

[9] R. Ortega, Arijn van der Schaft, Fernando Castanos, Alessando Astolfi. Control by Interconnection and standard passivity-based control of port Hamiltonian system[C]. IEEE Transaction on Automatic Control, 2008, vol. 53, pp.2527-2542.

DOI: 10.1109/tac.2008.2006930
