Principle Analysis of Profiled Bar Turning Peeling Machine

Abstract:

Through the study of regular polygon cross section continuous forming processing technology of rotary cutting machine, this article designed a profiled bar turning peeling machine. This machine is mainly composed of workpiece axis, cutter axis, feed device and pulling device, etc . Parallel mounted, workpiece axis and cutter axis rotate at a rotational speed ratio in the same direction so as to form complex turning motions, during which the cutting track of the knifepoint relative to workpiece axis forms a shape of approximate linear closed curve, at the same time, feed device and pulling device pull workpiece moving along the axis, through which this machine can complete a turning finish of a whole workpiece at a time. This article analyzed the turning peeling principle of profiled bar, established a motion trajectory equation for the knifepoint relative to the workpiece axis, analyzed the processing straightness error of turned profiled bar, and then derived the error calculation formula.

• Periodical: Applied Mechanics and Materials (Volumes 457-458)
• Pages: 486-489
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.457-458.486
• Online since: October 2013
• Authors: Hui Zhang*, Yan Chen
• Keywords: Profile Bar, Turning, Turning Peeling Machine

References

[1] Ma Man-hua, Development and design of steel pipe centreless skinning machine, J. Journal of North China University of Technology. 9(1997)63-67.

[2] SONG Yu-ming, HE Hong-sen, Design and calculations of the planetary gear train in the machine tool for square cutting, J. Machine Design and Manufacturing Engineering. 4(2001)60-61.

[3] Hu Chang-jun, Qian Rui-ming, Shi Lei, Simulation on regular polygon forming and locus of knifepoint based on rotary cutting machine tool, J. Transactions of the Chinese Society for Agricultural Machinery. 12(2009)255-260.

[4] Yu Shi-ming, Sun Hui-xiang, Yin Hai-meng, Research on regular polygon continuous forming principle and mathematical model based on straightness constraint condition, J. Machine Tool & Hydraulics. 2(2006)26-28.

[5] Zhao Han, Xu Lin-sen, Wu Yan-ming, Vector modeling of turning polyhedron movement and analysis on error, J. Transactions of the Chinese Society for Agricultural Machinery. 4(2007)154-157.
