Studying and Simulation Analysis for Rubber Track of Rescue Robot

Abstract:

Rubber track of Rescue Robot was dispersed into limited number of track blocks by the method of finite segment method used in flexible multibody dynamics. The two neighbor track blocks were connected by springs and dampers, then the moldel was become a multi-rigid-body system with flexible joint. Rubber track was modeled with the help of macro command used in the secondary development of virtual prototype technique software named ADAMS. Flexible connection was realized by the method of adding Bushing, and then a new method was proposed to build rubber track model. The obstacle-surmounting simulation of climbing the barrier of single step was carried out. It intuitively reflected the stress and deformation under the condition of climbing barrier. The method mentioned above laid good foundation for studying obstacle-surmounting abilities of the rubber-tracked robots and dynamic characteristic of the tracks.

• Periodical: Applied Mechanics and Materials (Volumes 457-458)
• Pages: 643-648
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.457-458.643
• Online since: October 2013
• Authors: Hong Wei Ma, Chuan Wei Wang
• Keywords: Bushing, Finite Segment Method, Obstacle-Surmounting Simulation, Rescue Robot, Rubber Track

References

[1] SUN Yunqiang. Rubber-tracked Chassis Structural Designand Experemental Simulation[D]. Daqing Petroleum Institute, (2010).

[2] ZHAO Dengke. Dynamiesof Multi-body Systems With Unilateral Constraint[D]. Dalian University of Teehnology, (2009).

[3] YAN Shaoze, Liu Bingqing, ect. Flexible multi-body system dynamics-finite segment element[J]. Journal of Hebei University of Technology, 1997, 03: 1-9.

[4] SUN Haijian. Simulation and Analysis of Stability for Crawler Crane Based on ADAMS[D]. Northeastern University, (2010).

[5] XU Zhiguan. Elastic Mechanics[M]. Higher Education Press, (2006).

[6] JIANG Shaojie, CHEN Weixu, LI Shangping. Discussion on the Modeling and simulation of Virtual Prototype for the Crawler Chassis of Small Scale Sugarcane Harvester Service Vehicle[J]. Equipment Manufacturing Technology, 2006, 03: 47-49.

[7] D. Rubinstein, R. Hitron. A detailed multi-body model for dynamic simulation of off-road tracked vehicles. Journal of Terramech 2004, 41: 163~173.

DOI: 10.1016/j.jterra.2004.02.004

[8] Mechanical Dynamics Ins. Adams Applications Manual [EB/OL], MSC, (2003).

[9] Ge Zhenghao Zhang Kaikai Liang Jinsheng Qu Yi. Dynamic Characteristic of Synchronous Belt Drive based on Virtual Prototype Technology[J]. Journal of Mechanical Transmission, 2011, 03: 64-66.
