A 3D Finite Element Simulation of Cold Roll Forming of Wrought Magnesium Alloy Sheets

Abstract:

In recent several years, although production of magnesium has risen dramatically, production of magnesium alloy sheet remains still at a very low level in practical use. The major barrier to greatly increased magnesium alloy use has been in still primarily high manufacturing cost as well as poor work ability of wrought magnesium sheet alloys. One of the author has investigated in cold roll forming of magnesium alloy, however detailed forming characteristics of the wrought magnesium alloy sheets has not been clarified. The aim of the study is to confirm possibilities of practical use of wrought magnesium alloy by using told roll forming process. A three dimensional elasto-plastic analysis by finite element method (FEM) has been conducted to examine the shapes of cross section, spring back characteristics, bending strains and longitudinal membrane strain of magnesium alloy sheet and cold rolled steel sheet during forming.

• Periodical: Applied Mechanics and Materials (Volume 459)
• Pages: 455-461
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.459.455
• Online since: October 2013
• Authors: Hisaki Watari*, Hidemitsu Hamano, Shi Ichi Nishida, Hayato Asou
• Keywords: Cold Roll Forming, Finite Element (FE) Simulation, Wrought Magnesium Alloys

References

[1] R. Grimes, R. J. Dashwood, A. Dorban, M. Jackson, S. Katsas, I. Pong, G. Todd, MaterialsScience Forum, Vol 511-551, (2007), p.357-p.364.

DOI: 10.4028/www.scientific.net/msf.551-552.357

[2] R. Grimes, M. Jackson, B. Moorhouse, R. Dashwood, Materialwissenshaft und Werkstofftechnik, Vol. 39, Issue 4-5, (2008), p.340-p.342.

[3] E. Doege et. al., Journal of materials processing technology, Vol. 105, (2001), 14-19.

[4] H. Watari et. al., Proc. of the European Metallugical Conference, EMC2003 (2003), 437-446.

[5] M. Kiuch, T. Koudabashi, F. Eto, Development of simulation model of roll-forming processes, J. Jpn. Soc. Technol. Plast. 27(306) (1986) 874-881 (in Japanese).

[6] Y. Onoda, T. Nagamachi, Finite element simulation of extroll-forming process of heavy gauge square steel pipe, J. Jpn. Soc. Technol. Plast. 30 (345) (1989) 1441-1446 (in Japanese).

[7] H. Watari, K. Davey, M.T. Rasgado, T. Haga, S. Izawa, Semisolid manufactruing process of magnesium alloys by twin-roll casting, Journal of materials processing technology, Vol. 155-156, 30, 2004, 1662-1667.

DOI: 10.1016/j.jmatprotec.2004.04.323

[8] H. Watari, T. Haga, K. Davey, H. Ona, S. Izawa, H. Hamano, T. Iwashita and M. Nakayama, Mechanical properties of magnesium alloy sheets produced by semi-solid roll strip casting, Materials Science Forum, Vols. 426-432, 2003, 617-622.

DOI: 10.4028/www.scientific.net/msf.426-432.617

[9] T. Hiroki and H. Watari, Analyses of cold roll forming for magnesium alloy sheet, 29th Mathematical Science Conference, 2010, Vol. 29, 69-70 (in Japanese).

[10] T. Hiroki, S. Nishida and H. Watari, Characteristic features of cold roll forming of wrought magnesium alloys sheet, The Proceedings of the 62th Japanese Joint Conference for the Technology of Plasticity, 2011, Vol. 62, 465-466 (in Japanese).
