Reconstruction of Geometrical Structure of Claw of Mole Rat (Scaptochirus moschatus) and Finite Element Analysis of Claw against Soil

Abstract:

Mole rat, a typical soil-burrowing animal, has high working efficiency during digging procedure, its claws are good biomimetic prototypes, and the geometrical structure of its claws and its movement type during digging can provide certain foundation for improving the design of the tillage implement. In this paper, based on the reverse engineering, the original data points of the claw was collected by a 3D laser scanner, then the accurate surface of the claw was created by using special software of reverse engineering on the premise of point-curve-surface method. The reconstructed CAD model was established in Pro/E software, and the model of interaction between the claws of mole rat and soil was obtained. The finite element method (FEM) was utilized to simulate the interaction of the claw against soil. The simulated results showed that the movement type of claw of mole rate during digging could get lower cutting resistance and bigger impact to soil.

• Periodical: Applied Mechanics and Materials (Volume 461)
• Pages: 108-113
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.461.108
• Online since: November 2013
• Authors: Wen Feng Ji, Jin Tong, Dong Hui Chen
• Keywords: Claw, Finite Element Method (FEM), Mole Rat (Scaptochirus moschatus), Reconstruction of Geometrical Structure, Reverse Engineering (RE)

References

[1] J. Tong, L. Q. Ren, B. C. Chen. Geometrical morphology, chemical constitution and wettability of body surfaces of soil animals. International Agricultural Engineering Journal, 3 (1994) 59-68.

[2] J. Tong, J. Y. Sun, D. H. Chen, S. J. Zhang. Geometrical features and wettability of dung beetles and potential biomimetic engineering applications in tillage implements. Soil and Tillage Research, 80 (2005) 1-12.

DOI: 10.1016/j.still.2003.12.012

[3] L. Q. Ren, X. B. Xu, B. C. Chen, X. X. Cui, Y. M. Wang, B. L. Zhang, L. H. Ge, G. P. Jin. Initial research on claw shapes of the typical soil animals. Transactions of the Chinese Society of Agricultural Machinery, 21 (1990) 44-49.

[4] B. C. Chen, L. Q. Ren, X. B. Xu, X. X. Cui, Y. M. Wang, B. L. Zhang, L. H. Ge, G. P. Jin. Initial research on reducing soil adhesion of body surface shapes of the typical Soil animals. Transactions of the Chinese Society of Agricultural Engineering, 6 (1990).

[5] J. Tong, B. Z. Moayad, D. H. Chen, J. Y. Sun. Effects of biomimetic surface on designs on furrow opener performance. Journal of Bionic Engineering, 6 (2009) 280-289.

DOI: 10.1016/s1672-6529(08)60128-6

[6] L. Y. Liu, G. M. Zheng. General Zoology. Higher Education Press, Beijing, (1997).

[7] Information on http: /www. useless-facts. net/Animals. html.

[8] W. F. Ji, J. Tong, H. L. Jia, D. H. Chen, C. Y. Liu. Quantitative characteristic features of geometric structures of claws of mole rat. Transactions of the Chinese Society of Agricultural Engineering, 41 (2010) 193-198.

[9] W. F. Ji, D. H. Chen, H. L. Jia, J. Tong. Experimental investigation into digging performance of the claws of mole rat (Scaptochirus moschatus). Journal of Bionic Engineering, sup. (2010) S166–S171.

DOI: 10.1016/s1672-6529(09)60231-6

[10] J. Tong, N. Wu. Mathematical Models and Analysis of Profiles of the Clypeus Surface of Dung Beetle Coprisochus Motschulsky. Transactions of the Chinese Society of Agricultural Machinery, 37 (2006) 113-116.

[11] R. G. Scott, R. C. Richardson. Realities of biologically inspired design with a subterranean digging robot example. Proceedings of the 6th IASTED International Conference on Robotics and Applications, Cambridge, 2005, pp.226-231.
