CFD Analysis of Circle Grid Fractal Plate Thickness on Turbulent Swirling Flow

Abstract:

In this paper, steady state, incompressible, swirling turbulent flow through circle grid fractal plate has been simulated. The aim of the simulation is to investigate an effect of the circle grid fractal plate thickness in order to reduce swirling due to swirl disturbance in pipe flow. The simulation and analysis were carried out using finite volume CFD solver ANSYS CFX. Three different thickness of fractal plate were used in the simulation work with the thickness of 1 mm, 3 mm and 6 mm. The simulation results were compared with the pressure drop correlation of BS EN ISO 5167-2:2003 and turbulent model used, standard k-ε model gave the best agreement with the ISO pressure drop correlation. The effects of circle grid fractal plate thickness on the flow characteristics which are swirl angle and tangential velocity have been investigated as well.

• Periodical: Applied Mechanics and Materials (Volumes 465-466)
• Pages: 109-113
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.465-466.109
• Online since: December 2013
• Authors: Bukhari Manshoor, Izzuddin Bin Zaman, Mohamad Jaat, Amir Khalid
• Keywords: CFD, Fractal Plate, Turbulent Flow

References

[1] A. Yehia, M. S. Khalid, S. A. Hossam and M. N. Jaafar, CFD analysis of incompressibe turbulent swirling flow through zanker plate, in Engineering Applications of Computational Fluid Mechanics Vol. 3, No. 4, p.562–572 (2009).

DOI: 10.1080/19942060.2009.11015291

[2] R. C. Baker, Flow Measurement Handbook: Industrial Designs, Operating Principles, Performance and Applications, Cambridge University Press, 27–30. (2000).

[3] ISO (2003). ISO 5167: 2003 Measurement of Fluid Flow by Means of Pressure Differential Devices Inserted in Circular Cross-Section Conduits Running Full.

DOI: 10.3403/02774295u

[4] A. K. Quazzane and R. Benhadj, Flow Conditioners Design and Their Effects in Reducing Flow Metering Errors, in Sensor Review 22(3): 223–231 (2002).

DOI: 10.1108/02602280210433061

[5] B. Manshoor, I. Zaman, M. F. Othman and Amir Khalid, Experimental study of circle grid fractal pattern on turbulent intensity in pipe flow, in International Conference on Mechanical Engineering Research (ICMER 2013), Malaysia.

DOI: 10.1088/1757-899x/50/1/012014

[6] B. Manshoor, F. C. G. A. Nicolleau and S. B. M. Beck, The fractal flow conditioner for orifice plate flow meters, in Flow Measurement and Instrumentation, vol 22(3): pp.208-214. (2011).

DOI: 10.1016/j.flowmeasinst.2011.02.003

[7] B. Manshoor and Amir Khalid, Numerical investigation of the circle grids fractal flow conditioner for orifice plate flowmeters, in Journal of Applied Mechanics and Materials, Vol. 229-231 (2012), pp.700-704.

DOI: 10.4028/www.scientific.net/amm.229-231.700

[8] Fluent Inc. (2005). FLUENT 6. 2 User's Guide, 2005-01-04.
