A Squeegee Coating Apparatus for Producing a Liquid Crystal Based Bio-Transducer

Abstract:

Cholesteryl ester liquid crystals were discovered with a new application in sensing traction forces of single cells. The liquid crystal bio-transducer is produced by manual scraping of liquid crystals onto the petri dish, in which the technique is highly subjective to the skill of the user to produce homogeneously spread liquid crystal substrates. This paper describes the development of an apparatus used to produce a liquid crystal substrate using squeegee coating technique. It consists of a biaxial mechatronic system which is synchronously controlled in vertical and horizontal directions scraping the liquid crystal substrates evenly on the surface of a petri dish. The thickness of the liquid crystal was profiled using laser diffraction technique and the homogeneity of the liquid crystal films produced was examined in a crossed-polarizing microscope. At an angular speed of 1500 rpm and under a shear stress of 1.46 ± 0.72 kPa, the squeegee coating was found producing liquid crystal films at a thickness of 132 ± 23 μm on the surface of petri dishes. With the application of this apparatus, evenly spread liquid crystal coatings with control thickness in petri dishes were consistently produced. This has overcome the major problem of manually coating the liquid crystal substrates using a cell scraper.

• Periodical: Applied Mechanics and Materials (Volumes 465-466)
• Pages: 759-763
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.465-466.759
• Online since: December 2013
• Authors: Chin Fhong Soon*, Zai Peng Goh, Lee Chin Ku, Ten Ten Lee, Kian Sek Tee
• Keywords: Arduino Controller, Liquid Crystals, Scraping, Squeegee Coating, Stepper Motor

References

[1] N.L. Abbott, L. N., C.J. Murphy, L. -L. Ching, and C. -H. Jang, Engineering interfaces to cells using synthetic liquid crystals. European Cells and Materials 10: 5 (2005) CS1.

[2] J.M. Brake, M.K. Daschner, Y. -Y. Luk, and N.L. Abbott, Biomolecular interactions at phospholipid-decorated surfaces of liquid crystals. Science, 302: 5653 (2003) 2094-(2097).

DOI: 10.1126/science.1091749

[3] N. Lockwood, J.C. Mohr, L. Ji, C.J. Murphy, S.P. Palecek, J.J. d. Pablo, and N.L. Abbott, Thermotropic liquid crystals as substrates for imaging the reorganization of matrigel by human embryonic stem cells. Advanced Functional Materials, 16: 5 (2006).

DOI: 10.1002/adfm.200500768

[4] S.J. Woltman, G.D. Jay, and G.P. Crawford, Liquid-crystal materials find a new order in biomedical applications. Nature Materials 6 (2007) 929-938.

DOI: 10.1038/nmat2010

[5] C.F. Soon, M. Youseffi, R.F. Berends, N. Blagden, and M.C.T. Denyer, Development of a novel liquid crystal based cell traction force transducer system. Biosensors & Bioelectronics, 39 (2013) 14-20.

DOI: 10.1016/j.bios.2012.06.032

[6] C.F. Soon, M. Youseffi, T. Gough, N. Blagden, and M.C.T. Denyer, Rheological characterization of the time-dependent cholesteric based liquid crystals and in-situ verification. Materials Science and Engineering C, 31: 7 (2011) 1389-1397.

DOI: 10.1016/j.msec.2011.05.006

[7] C.F. Soon, M. Youseffi, N. Blagden, R. Berends, S.B. Lobo, F.A. Javid, and M. Denyer, Characterization and biocompatibility study of nematic and cholesteryl liquid crystals in Proceedings of the World Congress on Engineering 2009. pp.1872-1875.

DOI: 10.1007/978-3-642-03900-3_4

[8] K. Takatoh, M. Hasegawa, M. Koden, N. Itoh, R. Hasegawa, and M. Sakamoto, Alignment technologies and applications of liquid crystal devices. Taylor & Francis, London. (2005).

DOI: 10.1201/9780367800949

[9] K. Yeun-Tae, Seongmo Hwang, H. Jong-Ho, and L. Sin-Doo, Alignment layerless flexible liquid crystal display fabricated by an imprinting technique at ambient temperature. Applied Physics Letters, 89: 17 (2006) 1-3.

DOI: 10.1063/1.2364866

[10] M. Schadt and W. Helfrich, Voltage dependent optical activity of a twisted nematic liquid crystal. Applied Physics Letters, 18, (1971): 127 (1971) 1-2.

DOI: 10.1063/1.1653593

[11] L. Ying-Jyh, u.H. Chain-Sh, and W. Shin-Tson, Dipping and photo-induced liquid crystal alignments using silane surfactants. Japanese Journal of Applied Physics, 39 (2000) L90-L93.

DOI: 10.1143/jjap.39.l90

[12] H. Sato, K. Miyashita, M. Kimura, and T. Akahane, Study of liquid crystal alignment formed using slit coater. Japanese Journal of Applied Physics, 50: 01BC16 (2011) 1-4.

DOI: 10.1143/jjap.50.01bc16

[13] S. Curry and A. Schawlow, Measuring the diameter of a hair by diffraction. American Journal of Physica A: Statistical and Theoretical Physics (Amsterdam), 42: 5 (1974).
