Research on the Influence of Bending Unloading Effect on Elongation in Cold Steel Strip Tension Leveling

Abstract:

Based on the fundamental assumption of the stretch-bending straightening theory and applying the elastoplastic theory, the paper analyzes and deduces the distribution and change of stress and strain of strip in the bending springback, raising that bending unloading will increase the elongation of the neutral layer of the strip. Then, through the conditions set-up of the finite element simulation model and results of data analysis, we found the effect of different tension and bending degree on the elongation for the neutral layer of the cold strip in process of unloading, and this kind of influence is described quantitatively.

• Periodical: Applied Mechanics and Materials (Volume 470)
• Pages: 330-334
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.470.330
• Online since: December 2013
• Authors: Bing Chen, Hai Hai Lin, Rui Juan Guo, Jian Hua Shu
• Keywords: Bending Unloading Effect, Cold Steel Strip, Elongation, Finite Element Method (FEM), Tension Leveling

References

[1] L. Xiao, The research of metal strip continuous stretch bending deformation mechanism of straightening [D]. Beijing: University of Science and Technology Beijing, 1999 (In Chinese).

[2] J.C. Wang, Mechanism of deformation in stretch bending and straightening [J]. Wuhan university of science and technology journal(JCR science Edition), 2008 31(2): 210-213 (In Chinese).

[3] L. Steinwender, A KainzK Krimpelstätter K Zeman Computational analysis of the curvature distribution and power losses of metal strip in tension levelers [J] Materials Science and Engineering 2010(10): 1-10.

DOI: 10.1088/1757-899x/10/1/012135

[4] W.G. Wang, Research on Mechanism and Technology of Tension Leveling [D], Beijing University of Science and Technology Beijing, 2008 (In Chinese).

[5] T.L. Yu, L.Z. Zhang, Plastic bending theory and its application [M]. Beijing: Science Press, 1992(In Chinese).
