The Used of Pedal-Pad Effective Amplitude Transmissibility Value to Predict Size of Comfortable Pedal-Pads

Abstract:

Vibration transmissibility from a car body to pedal-pad could result to drivers discomfort and fatigue, which may lead to health problems. Vibration transmissibility occurs when the vehicle engine is turned on and vibration is transmitted from the car body to pedal-pad in this research Pedal-pad effective Amplitude Transmissibility (PEAT) value was used to predict suitable size of the pedal-pad that could provide comfortable operation of the pedal. In this study, the variables are the three different sizes of pedal-pads and data was recorded while the car was moving on the road at constant speed with three different sizes of pedal-pads. The data was measured in root mean square (r.m.s) unit, of the frequency weighted acceleration (m/s²) for every minute. The finding of the study shows that percentage PEAT_r.m.s of the three different sizes of pedal-pad is greater than 100%. It shows that vibrations to pedal-pads are greater than vibration from the car body consequentially it means that the foot on the pedal is exposed to higher vibration transmissibility than the foot on the floor.

• Periodical: Applied Mechanics and Materials (Volume 471)
• Pages: 52-58
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.471.52
• Online since: December 2013
• Authors: A.R. Yusoff, Baba M. Deros, D.D.I. Daruis
• Keywords: Car Body, Pedal-Pad Effective Amplitude Transmissibility (PEAT), Pedal-Pads

References

[1] Miyajima, C., Nishiwaki, Y., Ozawa, K., Wakita, T., Itou, K., Takeda, K., & Itakura, F, Driver Modeling Based on Driving Behavior and Its Evaluation in Driver Identification. Proceedings of the IEEE. 95(2) (2007) 427-437.

DOI: 10.1109/jproc.2006.888405

[2] Groeger, John A., Understanding Driving: Applying Cognitive Psychology to a Complex Everyday Task, Psychology Press, Philadelphia USA, (2000).

DOI: 10.1002/acp.810

[3] Hoedemaeker, Marika., Driving with intelligent, Phd Thesis : Delft University Technology, Netherlands, (1999).

[4] M.J. Griffin, Handbook of Human Vibration, Elsevier Academic Press, London, (1990).

[5] S. Nishiyama, N. Uesugi, T. Takeshima, Y. Kano, H. Togii, H, Research on Vibration Characteristics Between Human Body and Seat, Steering Wheel, and Pedals (Effects of Seat Position on Ride Comfort), Journal of Sound and Vibration. 236(1) (2000).

DOI: 10.1006/jsvi.2000.2862

[6] G.S. Paddan, M.J. Griffin, Effect of seating on exposures to whole-body vibration in vehicles, Journal of Sound and Vibration. 253(1) (2002) 215-241.

DOI: 10.1006/jsvi.2001.4257

[7] H. Douville, P. Masson, A. Berry, On-resonance transmissibility methodology for quantifying the structure-borne road noise of an automotive suspension assembly, Applied Acoustics. 67(4) (2006) 358-382.

DOI: 10.1016/j.apacoust.2005.07.002

[8] A.E. Ducan, F.C. Su, W.I. Wolf, Understanding NVH Basic, International Body Design and Engineering Conference IBEC. (1996) 111-116.

[9] Y. Yu, N.G. Naganathan, R.V. Dukkipati, A literature review of automotive vehicle engine mounting systems, mechanism and machine theory. 36 (2001) 123-142.

DOI: 10.1016/s0094-114x(00)00023-9

[10] Tamboli, J.A. and Joshi, S.G., Optimum design of a passive suspension system of a vehicle subjected to actual random road excitations, Journal of Sound and Vibration, 219 (1999) 193-205.

DOI: 10.1006/jsvi.1998.1882

[11] Wang, X., Breton-Gadegbeku, B.L., & Bouzon, L., Biomechanical evaluation of the comfort of automobile clutch pedal operation, International Journal of Industrial Ergonomics, 34(3) (2004) 209-221.

DOI: 10.1016/j.ergon.2004.04.007

[12] Sanders, M.S. & McCormick, J., Human Factors in Engineering and Design, McGraw-Hill, New York, (1993).

[13] J.L.V. Niekerk, W.J. Pielemeier, J.A. Greenberg, The use of seat effective amplitude transmissibility ( SEAT ) values to predict dynamic seat comfort, Journal of Sound and Vibration. 260 (2003) 867-888.

DOI: 10.1016/s0022-460x(02)00934-3

[14] Jang, H., The Effect of Phase of Differential Vertical Vibration at the Seat and Feet on Discomfort, Journal of Sound and Vibration, 223(5) (1999) 785-794.

DOI: 10.1006/jsvi.1999.2156

[15] Tanaka, Y., Kaneyuki, H., Tsujiy, T., Miyazaki, T., Nishikawa, K., & Nouzawa, T., Mechanical and perceptual analyses of human foot movements in pedal operation, IEEE International Conference on Systems, Man and Cybernetics, (October) (2009).

DOI: 10.1109/icsmc.2009.5346943

[16] [ Tran, C., Doshi, A., & Trivedi, M. M., Modelling and prediction of driver behavior by foot gesture analysis. Computer Vision and Image Understanding, 116(3) (2012) 435-445.

DOI: 10.1016/j.cviu.2011.09.008
