Remote Testing of the UHF Radiation Field Generated by Corona Discharge of the Transmission Lines

Abstract:

The UHF radiation field generated by corona discharge of the two 500kV AC transmission lines was tested. The influencing factors of radiation field, including climate, bundle conductors number and test distance, were analyzed. Test results indicate that the field continuously arranges from 200MHz to 700MHz, mainly from 200MHz to 500MHz. The maximal measurement distance is 300 meters. The climate and bundled conductors number affect the radiation field obviously. The discharge will become intense when the temperature and humidity increase and bundle conductors number decays. The peak values of the electric field strength which decay rapidly with the distance increasing, can arrive several hundreds uV/m. The test results rich the UHF radiation field data and offer references to testing and evaluating the electromagnetic interference generated by corona discharge of ultra-high voltage transmission lines.

You might also be interested in these eBooks

Sensors, Measurement and Intelligent Materials II

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 475-476)

Pages:

12-15

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.475-476.12

Citation:

Cite this paper

Online since:

December 2013

Authors:

Gao Hui Fan*, Ming Wei, Xiao Feng Hu

Keywords:

Bundle Conductor, Climate, Corona Discharge, Electromagnetic Interference (EMI), Test Distance, Transmission Line, UHF Radiation Field

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] P. Sarma Maruvada 2000 Corona Performance of High-Voltage Transmission Lines(Printed in Great Britain by SRP Ltd., Exeter)p.55.

Google Scholar

[2] Fran s J on as Sollerkvist, Andrew Maxwell, Klas Roudn, etal . Evaluation, verification and operation al supervision of corona losses in Sweden[ J] . IEEE Transactions on Power Delivery, 2007, 22( 2) : 1210- 1217.

DOI: 10.1109/tpwrd.2006.881598

Google Scholar

[3] Chen Shuiming，Wang Lei, He Jinliang．Radio interference analysis from multi-circuits AC high voltage overhead power transmission lines [J]．Chinese Journal of Radio Science, 2002，17(6)：677-681(in Chinese).

Google Scholar

[4] Iliana E Portugues，Philip J Moore，Ian A Glover，et al . RF-based partial discharge early warning system for air insulated substations[J]. IEEE Trans. on Power Delivery，2009，24( 1) : 20-29.

DOI: 10.1109/tpwrd.2008.2005464

Google Scholar

[5] YUAN Qingyun , LIU Shanghe , JIA Xueyan, et al. Characteristics of Signal Radiated from Corona Discharge[J]. High Voltage Engineering, 2007，33(7)：107-110(in Chinese).

Google Scholar
