Study on the Working Fluid Conductivity Measuring Technology of MSWEDM

Abstract:

It analyzes measuring method of working fluid conductivity on the MSWEDM through the study of the working groove equivalent circuit model and the main factors affecting the conductivity measurement. It adopts ± 18V, 50Hz AC voltage to driving the measuring electrode in order to reduce the error caused by the electric spark machining the leakage current and polarization effect; the measurement system adopts with waterproof DJS-1CF (platinum black) conductance electrode in order to reduce the error caused by the capacitance effect. It study on the working fluid conductivity measuring technology that may help lay a foundation for it can real-time, on-line control research about the working fluid conductivity.

• Periodical: Applied Mechanics and Materials (Volumes 475-476)
• Pages: 68-71
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.475-476.68
• Online since: December 2013
• Authors: Cui Xia Guo, Kang Liu, Wen Ling Xie, Shun Yong Zhou
• Keywords: Measuring Technology, MSWEDM, Working Fluid Conductivity

References

[1] Z.Y. Wang, in: China Materials Engineering Canon, Volume twenty-fourth, Materials of Construction Process Engineering, edited by Chemical Industry Press, Chinese, NY (2005).

[2] C.X. Guo, K. Liu, W. L. Xie and S.Y. Zhou, in: Test Scheme Design of Working Fluid for Middle-speed WEDM, edited by Coal Mine Machinery Magazine, Chinese, NY (2013).

[3] R. Wang, in: Research on the intelligent control system of numeric control WEDM Working Fluid Design, edited by Lanzhou University, Chinese, NY (2009).

[4] Y. Zhang, in: Research on the cutting accuracy and surface quality of multi-cutting in HSWEND, edited by Nanjing University of Aeronautics and Astronautics Chinese, NY (2011).

[5] M. Wang, in: Inverse solutions for electrical impedance tomography based on conjugate gradients methods Measurement Science & Technology, Chinese, NY (2009).
