Nonlinear Calculating Method for Multi-Bar Luffing System of Giant Crane Considering the Sagging Effect

Abstract:

The luffing system of giant jib crane is usually consisted of rigid bars and flexible cables, and the weight of components causes sagging deformation and large displacement. In order to study the nonlinear method for multi-bar luffing system of giant jib crane, this paper completed theoretical analysis and example verification. Based on catenary theory, the equation of luffing strand was obtained. Spatial multi-bar equation of three bars was proposed and it was extended to any more bars. Then, equilibrium equations of components were written in sequence, and the equations of multi-bar luffing system were established with the elastic deformation of multi-bar and luffing strand. Finally, by taking the 2500-ton ring crane as an example, the results demonstrated that: the nonlinearity of combined multi-bar luffing system negatively influences the structural behavior, and the results calculated by the proved nonlinear method is more reasonable and closer to the actuality than the linear method, so it provides theoretical basis for engineering design and construction.

• Periodical: Applied Mechanics and Materials (Volumes 477-478)
• Pages: 307-314
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.477-478.307
• Online since: December 2013
• Authors: Qi Cai Zhou, Wen Jun Li*, Qing Long Wu, Xiao Lei Xiong
• Keywords: Giant Crane, Multi-Bar Luffing System, Nonlinear Calculating, Sagging Effect, Spatial Multi-Bar

References

[1] M. Zhao, W.H. Chen and J. Wang, the use and maintenance of crane luffing system , Constr. Machin. & Mainten. (4) (2009) 200-203.

[2] X.G. Meng, Bauma China 2010, BJ Sci. and Technol. Press, Beijing, (2010).

[3] C. Da, Sany's crawling crane SCC86000TM leaves the production line, Constr. Machin. & Mainten. (6) (2011) 76.

[4] C. Da, Zoomlion's crawling crane ZCC3200NP leaves the production line, Constr. Machin. & Mainten. (6) (2011) 121.

[5] Information on http: /www. mammoet. com/Documents/PDF/Mammoet Equipment/Ring Cranes/MSG-80. pdf.

[6] Information on http: /www. sarens. ru/media/catalog/Sarens%20SGC-120/Sarens%20SGC120. pdf.

[7] J.Q. Chen, P.Y. Zhang, Engineering Mechanics, 2nd edition. Higher Educ. Press, Beijing, (2009).

[8] S.Z. Shen, C.B. Xu, C. Zhao, Y. Wu, Design of cable structures, 2nd edition. Chin. Archit. & Building Press, Beijing, (2006).

[9] X. Wang, F.Z. Qu, X.D. Gao, Research on the nonlinear method for the flexible components of crane luffing system, Machin. Des. & Manuf. (1) (2001) 38-40.

[10] Applied Mathematics department of Tongji University, Advanced mathematics, 5th edition. Higher Educ. Press, Beijing, (2002).

[11] China Machinery Industry Federation, GB3811-2008 Design rules for cranes, Chin. Zhijian Publ. House, Beijing, (2008).

[12] Information on http: /209. 195. 157. 104/DOWNLOAD/A416. 1216860-1. pdf.

[13] Y.J. Ren, Numerical analysis using MATLAB: MATLAB6. X, 7. X, Higher Educ. Press, Beijing, (2007).
