The Effect of Hole behind Lining on Safety of Tunnel

Abstract:

ABAQUS finite element analysis software and load - structure method are adapted in this paper and the structure is simplified as a two-dimensional plane model. 25 kinds of working condition including five hole sizes: 0.6m, 1.2m, 1.5m, 1.8m, 2.1m and five hole positions varying from vault to arch springing are studied and the safety factor distribution of lining are obtained. By comparing the safety factor at dangerous section in lining with hole to that in no damage lining , a convenient evaluation method about the effect of hole to lining safety is proposed.

• Periodical: Applied Mechanics and Materials (Volumes 477-478)
• Pages: 600-603
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.477-478.600
• Online since: December 2013
• Authors: Jun Liu, Guan Hua Zhang
• Keywords: Hole, Lining, Numerical Simulation, Safety Evaluation

References

[1] H .J. Liu : The research on highway tunnel health diagnosis calculation model Ph. D of tongji university, shanhai (2007).

[2] J. Yu, C. He: Highway traffic science and technology. Vol. 25(2008), p.104.

[3] H. J. Liu, C. C. Xia, Y. C. Cai: Highway tunnel . Vol. 4 (2007), p.21.

[4] M. Li, H. K. Chen, F. W. Xiong: Journal of chongqing jiaotong university, Vol. 30(2011), p.398.

[5] D. L. Chen: Reinforced concrete member design principle and the numerical example (Chinese building industry press , Beijing 2005).
