Dynamics of Turbocharger Rotor with Spin Softening Effect

Abstract:

The solid model of a turbocharger rotor was simulated for the rotordynamic analysis by use of finite element method.The dynamic equations for the solid model were deduced from the rotatory effects and gyroscopic inertia.The program was developed to determine the bending,torsional and their couplied vibration models.Calculations show that both the spin softening and stress stiffening effects have significant influence on the forward and backward whirl modes,and the torsional vibration frequency doesn’t change with the increase of rotor speed.The couplied bending-torsional vibration may be took place as excited.The accuracy of the solid model and the solution techniques have been demonstrated by comparison with other results.

• Periodical: Applied Mechanics and Materials (Volumes 477-478)
• Pages: 90-94
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.477-478.90
• Online since: December 2013
• Authors: Xue Shi Yao*, Chun Long Zheng, Yi Feng Liao
• Keywords: Couplied Vibration, Rotordynamic, Spin Softening, Stress Stiffening, Turbocharger

References

[1] Bernhard Schweizer, Mario Sievert. Nonlinear oscillations of automotive turbocharger turbines[J]. Journal of Sound and Vibration. 2009, 321(3-5): 955–975.

DOI: 10.1016/j.jsv.2008.10.013

[2] R.G. Kirk A.A. Alsaeed E.J. Gunter. Stability Analysis of a High-Speed Automotive Turbocharger[J]. Tribology Transactions. 2007, 50(3): 427-434.

DOI: 10.1080/10402000701476908

[3] P Bonello. Transient modal analysis of the non-linear dynamics of a turbocharger on floating ring bearings[J]. Proceedings of the Institution of Mechanical Engineers, Part J: Journal of Engineering Tribology. 2009 , 223(1): 179-93.

DOI: 10.1243/13506501jet436

[4] Guangchi Ying, Guang Meng, Jianping Jing. Turbocharger rotor dynamics with foundation excitation[J]. Archive of Applied Mechanics. 2009, 79(4): 287-299.

DOI: 10.1007/s00419-008-0228-3

[5] Rao J.S., Sreenivas,R., Veeresh C.V., 2002, Solid Model Rotor Dynamics, Paper presented at the Four teenth U.S. National Congress of Theoretical and Applied Mechanics, Blacksburg[D], VA, 23-28 June (2002).

[6] Rao J S, Sreenivas R. Dynamics of a three level rotor system using solid elements[J]. Society of Mechanical Engineers, 2003, 4(6): 16-19.

[7] Xia Boqian, Yu Lie, Xie Youbai. Study on lateral-torsional coupling vibration model of gear-rotor-bearing system[J]. Journal of Xian Jiaotong university. 1997, 31(12): 93-99.

[8] Chai Shan, Gao Lianyong. Whole transmission matrix method for coupled bending-torsional vibration analysisof multi-rotor system[J]. Journal of Machine Design. 2005, 22(1): 8-10.

[9] P J Murtagh, B Basu, B M Broderick. Mode acceleration approach for rotating wind turbine blades[J]. Proc. Instn Mech. Engrs Part K: Muti-body Dynamics. 2004, 218(7); 159-167.

DOI: 10.1243/1464419042035962

[10] Corbo, M. A, Malanoski S.B. Practical Design Against Torsional Vibration[D]. In Proceedings of the Twenty-Fifth Turbomachinery Symposium. 1996: 189-222.

[11] Marcelo Areias Trindade, Rubens Sampaio. Dynamics of beams undergoing large rotations accounting for arbitrary axial deformation[D]. ENIEF 2003-XIII Congreso sobre Métodos Numéricos y sus Aplicaciones, Mecánica Computacional, 2003, Vol. XXII: 2591-2611.

DOI: 10.2514/2.4957

[12] LIAO Ai-hua, SUI Yong-feng, WU Chang-hua. Dynamic characteristics analysis of turbocharger rotor based on gyro effect[J]. Chinese internal combustion engine engineering, 2009, 30(4): 68-73 (in chinese).
