The Meshing Efficiency Analysis of Coupled Planetary Gear Reducer

Abstract:

This paper focus on the meshing efficiency of 2K-2H type planetary gear reducer. First, according to the concept of train value equation, the kinematic design of 2K-2H type planetary gear reducers is carried out. Then, based on the latent power theorem, the meshing efficiency equation of 2K-2H type planetary gear reducer is derived. According to the meshing efficiency equation, the meshing efficiency of 2K-2H type planetary gear reducer can be analyzed. The 2K-2H type planetary gear reducer has the following characteristics: 1. There is a problem of power circulation, 2.Larger reduction ratio makes less meshing efficiency, 3.For the same reduction ratio, larger value |ξ₄₂| (|ξ_α|) will get better meshing efficiency, and 4.The better quality of gears (manufactured by grinding) will produce much better meshing efficiency.
