Using ADAMS Application on Mechanism Simulation of New Multiaxis Machines

Abstract:

Aerospace industry or manufacturing industries might demand high class more-axis CNC machine tools for the high accuracy needs for machining. The multiaxis CNC machine development in simulation of the new model application seems to be necessary for the market. The main purpose of this paper is to study the mechanisms of new model multiaxis CNC machine tools and build process to develop the characteristics of machine tools. Through the computer simulation and graphic animation, users can observe their relationships of each movement on the new model multiaxis CNC machine tools. Using ADAMS to realize the motion commands and coordinate the kinematics is proposed. The prototype demonstrates the feasibility and kinematics analysis of new model five-axis CNC for real machine.

• Periodical: Applied Mechanics and Materials (Volumes 479-480)
• Pages: 396-400
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.479-480.396
• Online since: December 2013
• Authors: Yi Ming Lee, Kuei Shu Hsu, Shyue Bin Chang
• Keywords: Adam, Computerized Numerical Control (CNC), Multi-Axis

References

[1] Po-Wen Lue, The dynamic analysis of mlti-missile launcher system in the application of ADAMS simulation, the 2th research, Chung-San Institute of Science and Technology, (2006).

[2] Suh-Ken Wang, 3D motion simulation to the mechanism of CNC 4 axis machining center, Taiwan ADAMS user seminar and academic thesis delivery, (2002).

[3] Chia-Pin Chang, The simulation and analysis of joint truck in steering performance, The Military Combined Services- Logistic.

[4] Jung-Shiin Hung, The kinematics and collision simulation and analysis of 6 axis CNC machining center, master's thesis, Mechanic Engineering, National Chung -Chang University, (2005).

[5] Chien-Jen Ding, 3D motion simulation and dynamic analysis of track vehicle, master's thesis, Mechanic Engineering, Da-Ya University, (2000).

[6] Tsan-Ni Fu, Computer aid design—ADAMS basic application manual, Kao-Lie Book Company, Taipei, (2004).

[7] Sang-Feng Shiah, The rigidity analysis of virtue dual axis linear guide platform", master, s thesis, Mechanic Engineering, National Yun-Lin Technology University, (2002).

[8] D. Zhang, C.M. Gosselin, Kinetostatic analysis and design optimization of the Tricept machine tool family. ASME J Manuf Sci Eng 2002; 124: 725–33.

DOI: 10.1115/1.1471529

[9] D. Zhang, Kinetostatic analysis and optimization of parallel and hybrid architectures for machine tools. Ph.D. thesis, Laval University, Quebec, (2000).

[10] C. R Boer, L. Molinari-Tosatti, Smith KS., Parallel kinematic machines. London: Springer; (1999).

[11] Physik-Instrumente, Hexapod 6 axis micropositioning system. In: supplement to the Catalog no. 111/112; 1997, pp.36-7.
