A Practical Approach to Detection and Analysis of Time-Varying Waveform

Abstract:

The power quality has attracted considerable attention from both utilities and users due to the development of sensitive electronic equipment in power system network. A novel method for detecting and localizing power quality disturbance based on wavelet neural network is presented. The wavelet transform is established on decomposition of a signal according to time-scale using basis functions with adaptable scaling properties known as multiresolution analysis. The wavelet transform expands a signal not in terms of a trigonometric polynomial but by wavelets, generated using transition and dilation of a fixed wavelet function. The feature obtained from wavelet transform coefficients are inputted into the neural network for power quality disturbance pattern recognition. The improved network algorithm is utilized to complete the network structure initialization. The fundamental component of the signal is estimated to extract the mixed information using wavelet network, and then the disturbance is acquired by subtracting the fundamental component. The simulation results show that the proposed method is more sensitive to signal singularity, and achieves better performance over traditional method.

• Periodical: Applied Mechanics and Materials (Volumes 48-49)
• Pages: 1-4
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.48-49.1
• Online since: February 2011
• Authors: Jing Bo Liu, Gui Fen Zhao
• Keywords: Detection, Fundamental Component, Localization, Network Structure, Power Quality Disturbances, Signal Decomposition, Wavelet Neural Network (WNN)

References

[1] M. P. Papadopoulos, S. A. Papathanassiou, and S. T. Tentzerakis, in: Modeling of induction machine main flux saturation in the arbitrary reference frame—a case study on wind turbine self-excitation in Proc. Int. Conf. Electric Machines, Vigo, Spain, (1996).

[2] N. G. Boulaxis, S. A. Papathanassiou, and M. P. Papadopoulos, in: Wind turbine effect on the voltage profile of distribution networks[J]. Renew. Energy, 2002, 25(3): 401–415.

DOI: 10.1016/s0960-1481(01)00061-1

[3] A. Sannino, M. G. Miller, and M. H. J. Bollen, in: Overview of voltage sag mitigation in Proc. IEEE Power Eng. Soc. Winter Meeting. 2000, 4: 2872–2878.

DOI: 10.1109/pesw.2000.847340

[4] L. Kojovic and S. Hassler, in: Application of current limiting fuses in distribution systems for improved power quality and protection[J]. IEEE Trans. Power Del, 1996, 12(2) : 791–800.

DOI: 10.1109/61.584376

[5] E. R. Collins and A. Mansoor, in: Effects of voltage sags on AC motor drives in Proc. IEEE Textile, Fiber, Film Industry Annual Technical Conf, (1997).

DOI: 10.1109/texcon.1997.598533

[6] G. Gerdes and F. Santjer, in: Power quality of wind turbines and their interaction with the grid in Proc. Eur. Wind Energy Conf, Thessaloniki, Greece, Oct, (1997).

[7] T. Thiringer, in: Power quality measurements performed on a low-voltage grid equipped with two wind turbines[J]. IEEE Trans. Energy Conver, 1996,. 11(3): 601–606.

DOI: 10.1109/60.537031

[8] M. B. Djuric and V. V. Terzija, in: A new approach to the arcing faults detection for fast autoreclosure in transmission systems[J]. IEEE Trans. On Power Delivery, 1995, 10(4): 793-1798.

DOI: 10.1109/61.473378

[9] T. Zheng, E. B. Makram, and A. A. Girgis, in: Power system transient and harmonic studies using wavelet transform[J]. IEEE Trans. Power Deliver, (1999).

DOI: 10.1109/61.796241
