Online Monitoring ICE Powers Based on the Crankshaft Angular Vibration

Abstract:

A new method of online monitoring ICE powers based on the crankshaft angular vibration is proposed. It has deduced that when each cylinder works uniformly at a certain rotating speed, and the vth order angular vibration mode of crankshaft nears plane vibration mode such as “quasi-rigid body model” or “quasi-trapeziform model”, so a cubic polynomial can represent the relationship between the vth order angular vibration displacement amplitude of the crankshaft reference point and the engine powers, thereby the angular vibration of reference point could be used to online monitor engine powers. Through the simulation and experimental researches on a 6240 and a 4100 diesel engine, it shows that the engine powers fitted with the angular vibration displacement amplitudes of reference point are close to the measured or theoretical powers comparatively, and the maximum errors is only 2.95%, which verifies the feasibility and practicability of the method consequently.

• Periodical: Applied Mechanics and Materials (Volumes 48-49)
• Pages: 773-778
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.48-49.773
• Online since: February 2011
• Authors: Chun Rong Hua, Da Wei Dong, Bing Yan, Ming Heng Xu
• Keywords: Angular Vibration, Internal Combustion Engine (ICE), Monitor, Power, Vibration Mode

References

[1] Sun Yan; Wang Huiming; Yin Jing. Current situation and trend of development for ICE dynamometer[J]. Journal of Agricultural Mechanization Research, 2004(2), 43-44.

[2] Qi Yang; Han Beishan. Fault diagnosis of car [M]. China Communications Press. 1991: 408-412.

[3] Xu Yueding; Du Haiping; Liu Woye. The study on testing engine power in line [J]. Journal of Test And Measurement Technology, 1996(2), 366-370.

[4] Du Haiping; Xu Yueding; Liu Woye; Zhang Yingtang. Study on the data processing for the dynamic measurement of the power of an engine. International Symposium on Test and Measurement, Proceedings, pp.203-206, (1997).

[5] Han Tongqun; Xiao Shengfa; She Jianqiang. The improvement on speed measuring method applied to the measuring of vehicle engine power in condition of unload [J]. Journal of Hubei Automotive Industries Institute, 2002, (6): 1-3.

[6] Sarna D S; Steyaert J W. Diagnostic equipment development for military vehicle application [J]. SAE Transactions 780029.

[7] Jiang Yao-hua; Chen Jun; Qiao Hongyu. Experimental investigation on power measurement of internal-combustion engine at none-external load[J]. Journal of Agricultural Mechanization Research. 2007(3), 178-179.

[8] Wang Zhaohui; Zhang Laibin; Liu Yuhui; Liu Shoudao. Measurement of engine power using its cylinder vibration signal[J]. Journal of Vibration, Measurement & Diagnosis. 2001, 21(2): 125-130.

[9] Jiang Aihua; Wang Wei; Li Xiaoyu; Zeng Guojun. Measurement of engine power using cylinder-head vibration signals[J]. Transactions of the Chinese Society of Agricultural Engineering. 2006, 11: 117-120.

[10] Douglas, R.M.; Steel, J.A. 1; Reuben, R.L.; Fog, T.L. On-line power estimation of large diesel engines using acoustic emission and instantaneous crankshaft angular velocity[J]. International Journal of Engine Research, 2006(7): 399-410.

DOI: 10.1243/14680874jer00206

[11] Varshavskii, M.Z. Instrument for measuring the power of an engine on a testbed[J]. Measurement Techniques, 1984, 8(27): 731-732.

DOI: 10.1007/bf00861141

[12] Yilmaz, Emin. New sensor and instrumentation for relative cylinder power measurements on internal combustion engines[J]. ASEE Annual Conference and Exposition, Conference Proceedings, 2005: 10793-10808.

DOI: 10.18260/1-2--11199

[13] Yan Bing. The key technology study on fault diagnosis system of ICE based on angular vibration of crankshaft [D]. Chengdu: Southwest Jiaotong University, 2005: 77-79.

[14] Zhu Menghua. Vibration and Noise Control of ICE[M]. The Publishing Company of Defense Agriculture, 1995: 38-40.

[15] Wang Xin. Development of protable ICE fault diagnosis system using crankshaft angular vibration signals[D]. Chengdu: Southwest Jiaotong University, 2005: 49-57.

[16] Hua Chunrong; Yan Bing; Dong Dawei; Xu Mingheng. Misfiring method for identifying angular vibration mode of ICE crankshaft[J]. Journal of Southwest Jiaotong University, 2008(43)4: 478-482.

DOI: 10.1109/icoip.2010.120
