Quasi Resonant Direct Power Control of Three-Phase Grid-Connected Inverters in Distributed Generation Systems

Abstract:

The paper proposes a quasi resonant direct power control algorithm for three-phase grid-connected inverters without grid voltage sensors in distributed generation systems. According to the active and reactive power references, grid virtual flux and the inverter output current references are calculated. In order to accurately and fast track the output current references, the quasi proportional resonant (QPR) controller is used. The theoretical principle of this method is discussed. The steady-state and dynamic experimental results of quasi resonant direct power control that can illustrate the operation and performance of the presented control strategy are displayed. It is shown that the control system exhibits several advantages, such as constant switching frequency, sinusoidal grid currents and good dynamic response. Experimental results are provided to demonstrate the effectiveness of the proposed control strategy.

• Periodical: Applied Mechanics and Materials (Volumes 48-49)
• Pages: 863-867
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.48-49.863
• Online since: February 2011
• Authors: Fang Ping Zhao, Yong Yang, Yi Yuan
• Keywords: Distributed Generation System, Quasi Proportional Resonant Controller, Quasi Resonant Direct Power Control, Virtual Flux

References

[1] Blaabjerg F，Teodorescu R， Liserre M, in: Overview of Control and Grid Synchronization for Distributed Power Generation Systems[J], IEEE Transactions on Industrial Electronics, 2006, 53 (5): 1398-1409.

DOI: 10.1109/tie.2006.881997

[2] Bose B K. Energy, in: environment, and advances in power electronics. IEEE Transactions on Power Electronic[J], 2000, 15(4): 688-701.

DOI: 10.1109/63.849039

[3] Kazmierkowski M P, Malesani L, in: Current control techniques for three-phase voltage-source PWM converters: a survey[J]. IEEE Transactions on Industrial Electronics, 1998, 45(5): 691-703.

DOI: 10.1109/41.720325

[4] Malinowski M, Kazmierkowski M P, Trzynadlowski A M, in: A comparative study of control techniques for PWM rectifiers in AC adjustable speed drives[J]. IEEE Transactions on Industrial Electronics, 2003, 18 (6): 1390-1396.

DOI: 10.1109/tpel.2003.818871

[5] Zmood D N, Holmes D G, Bode G H, in: Frequency-domain analysis of three-phase linear current regulators[J]. IEEE Transactions On Industry Applications, 2001, 37(2): 601-610.

DOI: 10.1109/28.913727

[6] Zmood D N, Holmes D G, in: Stationary frame current regulation of PWM inverters with zero steady-state error[J]. IEEE Transactions on Power Electronics, 2003, 18(3): 814-822.

DOI: 10.1109/tpel.2003.810852

[7] YANG Yong, RUAN Yi , YE Bing-ying, in: Deadbeat Predictive Current Control Method for Three-phase Grid-connected Inverters[J]. Proceeding of the CSEE, 2009, 29 (33): 40-46.
