Experimental Investigation of Projectile Impact Local Damage on Cementitious Composite Slabs

Abstract:

This paper describes the projectile impact resistance of cement based composite slabs. The resistance is evaluated on the basis of the presented experimental program. In the experiment, local damage was inflicted by impact of defined projectiles on specimens made from normal strength concrete (NSC), steel fiber-reinforced concrete (FRC), ultra-high performance concrete (UHPC) and ultra-high performance fiber-reinforced concrete (UHPFRC) with different fiber content. Deformable ogive-nose projectiles with diameter of 7.92 mm and mass of 8.04 g with impact velocity about 700 m/s were in the experiment hitting center of the specimens. Data from the measured and visual evaluation of specimen damage were used for comparison of specimen projectile impact resistance in relation to the used material.

• Periodical: Applied Mechanics and Materials (Volume 486)
• Pages: 301-306
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.486.301
• Online since: December 2013
• Authors: Tomáš Vavřiník*, Jan Zatloukal
• Keywords: Concrete, Fiber, Local Damage, Penetration Depth, Perforation, Projectile Impact, Scabbing, Spalling

References

[1] K. Nyström. Concrete Structures Subjected to Blast and Fragment Impacts: Numerical Simulations of Reinforced and Fibre-reinforced Concrete. Chalmers University of Technology, Göteborg, (2008).

[2] H. Pahl. Penetration of Projectiles into Finite Thick Reinforced Concrete Targets. Proceedings of 4th International Symposium on Interaction of Non-Nuclear Munitions with Structures, Panama City Beach, April 1989, 55.

[3] I. Latif, I. A. Rahman, A. M. A. Zaidi. Development of Empirical formula Prediction on Critical Impact Energy for Perforation Phenomena on Concrete Structures. Journal of Mathematics Research, 3 (2011) 83-87.

DOI: 10.5539/jmr.v3n1p83

[4] M.H. Zhang, V.P.W. Shim, G. Lu, C.W. Chew. Resistance of high-strength concrete to projectile impact. International Journal of Impact Engineering, 31 (2005) 825-841.

DOI: 10.1016/j.ijimpeng.2004.04.009

[5] T. Vavřiník. Odolnost vysokohodnotného betonu proti nárazu projektilu [Resistance of high-performance concrete to projectile impact] (bachelor thesis), 2012, Czech Technical University in Prague, Faculty of Civil Engineering.

[6] P. Máca , J. Zatloukal, P. Konvalinka: Development of Ultra High Performance Fiber Reinforced Concrete mixture, IEEE Symposium on Business, Engineering and Industrial Applications (ISBEIA), IEEE, 2012, 861-866.

DOI: 10.1109/isbeia.2012.6423015

[7] T. Krauthammer. Modern protective structures. CRC Press, Boca Raton, (2008).

[8] Q. M. Li, S.R. Reid, H.M. Wen, A.R. Telford. Local impact effects of hard missiles on concrete targets. International Journal of Impact Engineering, 32 (2005) 224-284.

DOI: 10.1016/j.ijimpeng.2005.04.005
