Investigation on Melting Phenomena Generated during Dynamic Formation of Al-Based Coating on Magnesium Alloy

Abstract:

The deposition behavior of Al-Si particle on magnesium alloy by supersonic particles deposition was investigated by numerical stimulation. The results demonstrated that critical velocity of sprayed particle reduced as its initial temperature increased; Temperature at interface increased rapidly and reached to the value higher than melting point of Al-Si particle and ZM5 magnesium substrate, which predicts the melting possibility for collision interface. Morphology and microstructure of Al-Si coating on magnesium alloy were analyzed by SEM and TEM. The results indicated that there existed large amount of nano/micro-scale grains produced by sputtering and impacting of the melting Al-Si jet. And obvious interface belt had been formed at brim of the deposited particles, nanocrystalline phase region generated by rapid solidification of melting Al-Si particles, justified the occurrence of interface melting phenomena.

• Periodical: Applied Mechanics and Materials (Volumes 488-489)
• Pages: 189-192
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.488-489.189
• Online since: January 2014
• Authors: Xiao Ming Wang*, Sheng Zhu, Xue Qiang Feng, Yu Xiang Liu
• Keywords: Magnesium Alloy, Melting Phenomena, Microstructure, Number Simulation

References

[1] Li Tiefan, Wang kai, Wu jie. Research Progress on Cold Spraying Device [J]. Thermal Spraying Technology, 2011, 3(2) 16-31.

[2] Wang Gong-han. Supersonic spraying technology [M]. Beijing: Scientific Press, (2005).

[3] Yang Yang. Metal composite explosive technology and physical metallurgy[M]. Beijing: chemical industry press, (2006).

[4] Zhou Xianglin, Zhang Jishan, Wu Xiangkun. Advanced cold spraying technology[M]. Beijing: Mechanical Industry Press, (2011).

[5] Grujicic M, Zhao C L, DeRosset W S, et al. Adiabatic shear instability based mechanism for particles/substrate bonding in the cold-gas dynamic spray process [J]. Materials & Design, 2004, 25(8): 681-688.

DOI: 10.1016/j.matdes.2004.03.008

[6] Wang A, Wielage B, Podlesak H, et al. High-resolution microstructure investigation of interfaces between light metal alloy substrate and cold gas-sprayed coatings[J]. Journal of Thermal Spray Technology, 2006, 15(2): 280-283.

DOI: 10.1361/105996306x108291

[7] Li W Y, Zhang C, Guo X, et al. Study on impact fusion at particle interface and its effect on coating microstructure in cold spraying deposition [J]. Scripta Material, 2006, 54(4): 665-669.

[8] Ma You-ping, Lu Xu-zhong, Xu Ke-wei. High-frequency Induction for Surface Alloying of Magnesium Alloy ZM5 and Its Corrosion Behavior [J], Rare Metal Materials and Engineering, 2003, 32(3): 191-192.

[9] Han Guo-feng. Research on preparation and properties of al-si alloy coating on magnesium alloy by cold spray [D]. Beijing: Academy of armored forces engineering, (2011).

[10] Li Wen-ya. Study on the effect of particle parameters on deposition behavior, microstructure evolution and properties in cold spraying [D]. ShanXi: Xi'an Jiaotong University, (2005).
