On the Stress Responses in Butt Joint under Izod Impact Testing

Abstract:

The response of the equivalent stress (Seqv) in adhesively bonded steel butt joint and the adhesive bondline during Izod impact test is studied using the finite element method (FEM) software ANSYS. The results obtained show that the highest value of the stress Seqv almost higher than the yield strength of the adherend reached within about 0.1 ms. The contour diagram of the stress Seqv is symmetrical to the axis along the half height of the specimen both in whole adhesively bonded steel butt joint and the adhesive layer. The peak value of the Seqv in adhesive increases first and then decreased when the action of the impact was over. The stress Seqv in both ends of the specimen kept to a relative lower value during impact procedure.

You might also be interested in these eBooks

Materials Science, Civil Engineering and Architecture Science, Mechanical Engineering and Manufacturing Technology

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 488-489)

Pages:

542-545

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.488-489.542

Citation:

Cite this paper

Online since:

January 2014

Authors:

Min You*, Kai Liu, Xiang Li, Ling Wu, Mei Li

Keywords:

Adhesives, Butt-Joint, Equivalent Stress, Izod Impact, Response, Steel

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] R. D. Adams and J. A. Harris: Int J of Adhesion and Adhesives. Vol. 16(1996), p.61.

Google Scholar

[2] K. Kihara, H. Isono, H. Yamabe and T. Sugibayashi: Int J of Adhesion and Adhesives. Vol. 23(2003), p.253.

Google Scholar

[3] M. You, Z. Li, X. L. Zheng, et al: Chinese J of Solid Mechanics, Vol. 29(2008, s1), p.291.

Google Scholar

[4] M. You, K. Liu, H. Z. Yu et al: Adv. Mater. Research, Vol. 644(2013), p.193.

Google Scholar

[5] M. You, J. L. Yan, X. L. Zheng, et al: Advanced Materials Research, Vol. 97-101(2010), p.763.

Google Scholar

[6] X. L. Zheng, L. Wu, M. You, et al: Adv. Mater. Research, Vol. 602-604 (2012), p.2279.

Google Scholar

[7] X. L. Zheng, M. Li, M. You, et al: Adv. Mater. Research, Vol. 644(2013), p.197.

Google Scholar
