Orientation Method Simulation in Twin Parallel Horizontal Wells

Abstract:

As traditional measurement while drilling (MWD) method cannot meet the high reliability, high precision requirements for drilling complex structure wells. A guided-orientation method based on rotating magnetic field has prominent advantages on the twin parallel horizontal wells and can apply in twin parallel horizontal wells. In this paper, RMRS, namely Rotating Magnet Ranging system, its operating principle was gave firstly while applied for drilling twin parallel horizontal wells. The rotating magnetic sub was characterized by a pair of orthogonal magnetic dipoles, and then build the model for positioning the twin parallel horizontal wells Finally, the authors used the Maxwell software to simulate the algorithm based on the scene environment, and then proves that algorithm is correct and useful for guiding the well to drill and keeping the twin wells parallel.

• Periodical: Applied Mechanics and Materials (Volumes 488-489)
• Pages: 728-731
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.488-489.728
• Online since: January 2014
• Authors: Mei Rong Liu*, Xiao Feng Shi, Qing Long Liu
• Keywords: Magnetic Dipole, Maxwell, Relative Orientation, RMRS, Twin Parallel Horizontal Wells, Well Spacing

References

[1] Jing Lin, Zhaohui Song, Yuheng Luo, Ling Liu. SAGD horizontal drilling technology［J］ . Drilling Technology Research Institute, Western Drilling Engineering Corporation of CNPC, Karamay, Xinjiang, 834000, 2010, 16－22.

[2] KUCKES A F, HAY R T, MCMAHON J, et al. New electromagnetic surveying /ranging method for drilling parallel horizontal twin wells ［R］. SPE 27466, (1996).

DOI: 10.2118/27466-pa

[3] GRILLS T L. Magnetic ranging technologies for drilling steam assisted gravity drainage well pairs and unique well geometries: a comparison of technologies ［R］. SPE 79005, (2002).

DOI: 10.2118/79005-ms

[4] MALLARY C R, WILLIAMSON H S, PITZER R, et al. Collision avoidance using a single wire magnetic ranging technique at Milne point, Alaska ［R］. SPE 39389, (1998).

DOI: 10.2118/39389-ms

[5] Binbin Diao, Deli Gao, Zhiyong Wu. Magnet ranging calculation method of twin parallel horizontal wells steerable drilling [J]. Journal of China University of Petroleum, 2011, 35(6): 71-75.

DOI: 10.1016/j.jngse.2015.10.037

[6] Dongkui Sun, Deli Gao, Binbin Diao, Baogang Yang. The application of the RMRS in heavy oil/super heavy oil development [J]. CHINA PETROLEUM MACHINERY, 2011, 39(7): 73-76.

[7] Yanbo Zong, Jun Zhang, Xiaofeng Shi, Feng Sun. A high- precision guidance method of wellbore trajectory based on the rotary magnetic dipole [J]. ACTA PETROLEI SINICA, 2011, 32(2): 1-5.

[8] Binbin Diao, DeliGao. A solenoid ranging guidance system while drilling [J]. ACTA PETROLEI SINICA , 2011, 32(6): 1061-10.
