Synthesized ADRC for One-Level Inverted Pendulum System through Combination of Separating and Assembling

Abstract:

Inverted pendulum system is the ideal study object of nonlinear system. The ADRC has good estimate for disturbances, strong robustness and using static decoupling instead of dynamical decoupling. The one-level inverted pendulum system can be regarded as composing of the pendulum angel system and the cart position system. The former is faster and the later is slower. The synthesized ADRC for one-level inverted pendulum system is built through combination of separating and assembling to reduce difficulty in optimizing ADRC parameters of the inverted pendulum system. The synthesized controller is simulated by Matlab under different parameters of the inverted pendulum. Simulation results show that the pendulum angle and the cart position are well controlled.

• Periodical: Applied Mechanics and Materials (Volumes 490-491)
• Pages: 794-797
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.490-491.794
• Online since: January 2014
• Authors: Wen Ping Li, Li Qiang Wu
• Keywords: Active Disturbance Rejection Controller, One-Level Inverted Pendulum System, State Feed-Back Controller

References

[1] X. Pan, L. Zhang and D. Huang: Micro Computer Information, Vol. 10(2007), p.4.

[2] A. Bradshaw and J. Shao: Robotica. Vol. 14(1996), p.397.

[3] X. Ruan, H. Cheng and L. Liang: Control Engineering of China. Vol. 4(2009), p.481.

[4] L. Wu, J. Han: CONTROL THEORY & APPLICATIONS, Vol. 21(2004), p.665.

[5] J. Du and J. Jiang: Applied Mechanics and Materials, Vol. 313-314(2013), p.553.

[6] J. Han: The Proc. of the 14th IFAC World Congress, Beijing, China(1999).

[7] Z. Gao: Proceedings of the 2003 American Control Conference(2003), p.4989.

[8] J. Zhang, G. Wang and L. He: Control Theory & Application, Vol. 22(2005), p.67.
