Performance of Conical Diffuser on Liquid Jet Gas Ejector

Abstract:

Liquid gas ejector uses liquid as the motive fluid and gas as the entrained fluid. The presence of gas in the liquid reduces the performance of the ejector, especially the diffuser. To observe the effect of entrained gas on the diffuser performance, a series of experiment was conducted.In this research, the motive flow rate was varied from 1.52 to 2.02 l/s and the entrained rate from 0.118 l/s to 0.944 l/s. Its effects on the pressure profile and pressure recovery were observed. If the entrained rate increase, the pressure of the throat upstream, as well as downstream, increase. In the diffuser, longer distance is needed for the pressure to reach its final value. Pressure recovery is mainly affected by void fraction. The higher the void fraction the lower the pressure recovery coefficient

You might also be interested in these eBooks

Advances in Applied Mechanics and Materials

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 493)

Pages:

145-150

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.493.145

Citation:

Cite this paper

Online since:

January 2014

Authors:

Daru Sugati, Indarto Indarto, Purnomo Purnomo, Sutrisno Sutrisno

Keywords:

Co-Current Flow, Diffuser, Downward Flow, Ejector, Pressure Recovery, Two-Phase Flow

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Brahim A.B., Prevost.M., Bugarel.L., 1984, Momentum Transfer in Verical Down flow Liquid Jet Ejector : Case of Self Gas Aspiration and Emulsion Flow, Int. J. Multiphase Flow Vol. 10, No. I, 79-94.

DOI: 10.1016/0301-9322(83)90061-7

Google Scholar

[2] Kandakure, M.T., Gaikar, V.G., Patwardhan A.W., 2005, Hydrodynamic aspects of ejectors, Chemical Engineering Science, 60, 6391 – 6402.

DOI: 10.1016/j.ces.2005.04.055

Google Scholar

[3] Cunningham R. G., 1995, Liquid Jet Pump for two Phase Flows, ASME Journal Fluids Engineering, vol. 117, 309-316.

DOI: 10.1115/1.2817147

Google Scholar

[4] Neve, R. S., 1991, Diffuser Performance in Two-Phase Jet Pumps. International Journal of Multiphase Flow, 17, 267-272.

DOI: 10.1016/0301-9322(91)90019-y

Google Scholar

[5] Thang, N.T., Davis,M. R, 1981, Pressure Distribution in Bubble Flow Through Venturis, International Journal of Multiphase Flow, 7, 191-210.

DOI: 10.1016/0301-9322(81)90005-7

Google Scholar
